As a professional manufacturer established in 2011, Deqing Leixin Coating Equipment Co., Ltd. offers a high-performance Industrial Electrostatic Powder Spray Coating Equipment System specifically designed for metal painting lines. Our system integrates advanced electrostatic technology and efficient powder recovery to deliver consistent, high-quality coatings while minimizing waste. With ISO9001 certification and a strong global presence, we provide reliable and cost-effective solutions for industries ranging from automotive parts to home appliances.
Key Features & Benefits:
Advanced Electrostatic Charging: High-voltage generator ensures uniform particle charging, increasing deposition efficiency and reducing overspray by up to 30%.
High-efficiency Powder Recovery: Cyclone + cartridge filter system (optional) achieves recovery rates of 95%-98%, significantly lowering powder costs and environmental impact.
PLC Touch Screen Control: Intuitive interface with preset parameters and real-time monitoring for easy operation and repeatable quality.
Modular & Customizable Design: Gun quantity, conveyor speed, and spray parameters can be tailored to fit specific production line requirements.
Durable Construction: Main frame made of high-quality stainless steel or carbon steel with anti-corrosion treatment, ensuring long service life in harsh workshop environments.
Low Maintenance: Easy-access filters, quick-change gun parts, and self-cleaning functions reduce downtime and maintenance costs.
Technical Specifications (Standard Configuration):
| Parameter | Specification |
| Input Voltage | 380V/440V 50/60Hz (3-phase) |
| Power Consumption | 0.5 – 2.5 kW (depending on configuration) |
| Number of Guns | 2 – 12 pcs (optional) |
| Spray Gun Voltage | 0 – 100 kV (adjustable) |
| Powder Output per Gun | Up to 500 g/min (adjustable) |
| Recovery Efficiency | ≥95% (with cyclone + filter) |
| Control System | PLC + Touch Screen (Siemens or equivalent) |
| Applicable Metal Types | Steel, aluminum, iron, stainless steel, etc. |
Our system is engineered to boost productivity while ensuring excellent coating uniformity and adhesion. By optimizing powder usage and reducing rework, customers typically see a return on investment within 6–12 months. The modular architecture also allows future upgrades, such as adding more guns or integrating with existing conveyor and curing ovens.
Why Choose Deqing Leixin?
With 12 years of manufacturing experience, a factory spanning 1,000–3,000 square meters, and a dedicated team of 51–100 employees, we have the capacity to deliver custom solutions efficiently. Our annual export value exceeds US$1–1.5 million, supplying to markets across North America, South America, Europe, Asia, Africa, and Oceania. Each system undergoes strict quality control in accordance with ISO9001 management standards. We provide comprehensive after-sales support including installation guidance, operator training, and spare parts availability. Shipments are arranged from Ningbo or Shanghai ports. Contact us now to discuss your specific metal painting line requirements and receive a tailored quotation.
Frequently Asked Questions
Q1: What is the typical powder recovery efficiency of your system?
A1: Our system can achieve a recovery efficiency of up to 95%–98% with the cyclone and cartridge filter combination, depending on the powder type and coating conditions.
Q2: Can the system be adapted for different metal sizes and shapes?
A2: Yes, the system offers adjustable gun positions, conveyor speed, and spray parameters to accommodate various workpiece geometries.
Q3: What power supply is required?
A3: Standard 380V/440V three-phase, 50/60Hz. Other voltages are available upon request.
Q4: Is the system easy to operate and maintain?
A4: Our PLC touch screen control makes operation intuitive. Maintenance is simple with easy-access filters and modular components.
Q5: Do you provide installation and training services?
A5: Yes, we offer on-site installation guidance, commission, and training for operators and maintenance staff.
Q6: What kind of powder can be used?
A6: The system is compatible with most thermosetting and thermoplastic powder coatings, including epoxy, polyester, hybrid, and polyurethane powders.
Q7: How long is the warranty period?
A7: Our standard warranty is 12 months from commissioning, with extended options available.
Q8: Can the system be integrated into an existing painting line?
A8: Absolutely. Our modular design allows easy integration with existing conveyors, ovens, and pre-treatment lines.
