Help CenterPLC Controlled Continuous Metal Powder Coating Line For Aluminum & Steel Components
Product Spotlights
Related Products
-
Manual Assisted Automatic Powder Coating Line for Irregular Metal PartsNegotiableMOQ: 1 Piece -
Fully Automatic Metal Powder Coating Line With Pretreatment & Curing Oven For Metal WorkpiecesNegotiableMOQ: 1 Piece
-
Auto Parts Wheel Rim Paint Painting Line With Powder Coating Spray Booth for Sheet MetalNegotiableMOQ: 1 Piece
-
Industrial Electrostatic Powder Spray Coating Equipment System for Metal Painting LineNegotiableMOQ: 1 Piece
-
High Efficiency Cyclone Recovery Metal Powder Coating Line Low Powder Waste Eco-FriendlyNegotiableMOQ: 1 Piece
Company Background: Deqing Leixin Coating Equipment Co., Ltd., established in 2011, is a professional manufacturer specializing in advanced powder coating solutions. With over a decade of experience and a factory spanning 1,000–3,000 square meters, we have supplied our reliable equipment to clients across North America, South America, Europe, Asia, Africa, and Oceania. Our team of 51–100 dedicated employees ensures every system meets the highest quality standards, supported by our ISO9001 certification. The PLC Controlled Continuous Metal Powder Coating Line For Aluminum & Steel Components represents our commitment to precision, efficiency, and adaptability.
This continuous coating line is engineered to deliver a uniform, durable finish on a wide range of metal substrates, including aluminum and steel. At its core, an advanced PLC system manages every stage — from pre-treatment to powder application and curing — ensuring repeatable results and minimal operator intervention. Whether you are processing small brackets or large structural parts, this line offers the flexibility and reliability demanded by modern manufacturing.
Key Technical Specifications
| Parameter | Value / Range |
|---|---|
| Control System | PLC with HMI touch screen interface |
| Line Speed | Adjustable 1.5 – 6.0 m/min |
| Curing Oven Temperature | 180°C – 220°C (uniformity ±5°C) |
| Conveyor Type | Overhead or floor chain – customizable |
| Powder Recovery System | Cyclone + cartridge filter (efficiency ≥98%) |
| Applicable Part Size | Up to 2.5m × 1.2m × 1.0m (configurable) |
| Power Supply | 380V / 3-phase / 50Hz (other voltages available) |
| Coating Thickness | 50 – 150 µm (adjustable) |
Product Features & Benefits
PLC Automation: The system’s programmable logic controller orchestrates all process parameters — conveyor speed, gun trigger, oven temperature — ensuring consistent output and reducing scrap. Operators can save multiple recipes for quick changeover between different parts or colors.
Continuous Operation: Designed for 24/7 production environments, the line incorporates heavy-duty components and efficient heat management to maintain uninterrupted performance. This translates to higher throughput and lower per-unit costs.
Superior Coating Quality: Electrostatic powder guns with advanced charging technology deliver a uniform cloud of powder, even on complex geometries. The curing oven provides precise temperature profiling to achieve excellent adhesion, impact resistance, and a smooth finish.
Energy Efficiency: The oven is insulated with high-density rock wool and equipped with a hot air recirculation system, reducing energy consumption by up to 20% compared to conventional designs. The PLC also optimizes idle time energy usage.
Material Versatility: Suitable for both aluminum and steel components, the line can handle different shapes (flat, tubular, casted) without extensive reconfiguration. Pre-treatment modules (e.g., iron phosphate or zirconium) can be integrated as needed.
Easy Maintenance: All major assemblies — conveyor chain, fans, filters, and spray booths — are designed for quick access. The PLC system logs operational data and alerts operators when filters need cleaning or bearings require lubrication.
Eco-Friendly Design: The closed-loop powder recovery system captures overspray and recycles it back to the feed hopper, achieving material utilization rates exceeding 95%. This minimizes waste and reduces environmental impact.
Global Compliance: The line is built with components meeting international electrical and safety standards. Control cabinets are IP54 rated and all high-voltage parts comply with CE requirements (certification available upon request).
Customization Options
We understand that every production facility has unique requirements. The PLC Controlled Continuous Metal Powder Coating Line can be tailored in several ways:
Pre-treatment stage: choose between 3-in-1 or 5-in-1 washing & phosphating systems.
Conveyor layout: straight, L-shaped, or multi-pass configurations.
Number of powder booths: single or dual for quick color changes (e.g., 5-minute color change option).
Oven length and heat source: electric, gas, or diesel burners.
Integration with upstream/downstream equipment (e.g., robotic loading, automated packaging).
All customizations are performed in-house by our experienced engineering team, ensuring fast delivery and seamless integration.
Reliability & Service
Deqing Leixin Coating Equipment Co., Ltd. stands behind every system we ship. Our ISO9001:2015 qualified production process includes rigorous testing of each module before factory acceptance. We provide:
Detailed documentation and installation drawings.
On-site startup supervision and operator training (available for international customers).
Remote support via phone, email, and video collaboration.
A comprehensive spare parts kit with each order.
With an annual export value of US$1M–US$1.5M and a global customer base, we have proven our ability to deliver and support powder coating lines across diverse markets — from Eastern Europe to Southeast Asia and the Americas. Our location in Huzhou, Zhejiang allows convenient container loading at Ningbo and Shanghai ports.
Ready to elevate your finishing capability? Contact our sales team to discuss your specific part dimensions, required throughput, and desired coating characteristics. We will propose a tailored solution that maximizes your return on investment.
Frequently Asked Questions
Q: What types of powder can be used with this line? A: The line is compatible with thermosetting powder coatings, including epoxy, polyester, hybrid, and polyurethane types. It can also handle metallic and textured powders with an optional feed system.
Q: How long does it take to change colors or powder types? A: With our quick-change booth design, color change can be completed in under 10 minutes (including purging and recovery cleaning). The PLC stores recipes to accelerate parameter adjustment.
Q: Does the line require special foundation or civil works? A: A level concrete floor with proper load-bearing capacity (typically ≥5 tons per square meter under the oven sections) is recommended. Our installation guide provides detailed requirements, and we can help with layout planning.
Q: What is the typical payback period for this equipment? A: The payback period depends on your production volume and existing process costs. Many customers achieve full ROI within 12–18 months due to reduced labor, material savings, and increased yield.
Q: Can the line handle both small and large parts simultaneously? A: Yes, the conveyor system can be configured with variable speed and adjustable hanger spacing. Different part sizes can be mixed as long as they fall within the maximum envelope; the PLC’s recipe management ensures optimal gun positioning.
Q: Do you provide training for operators and maintenance personnel? A: Absolutely. We offer on-site training for up to 5 personnel over 3–5 days, covering PLC operation, routine maintenance, troubleshooting, and safety procedures. Remote follow-up support is also available.
Q: What warranty do you offer? A: Standard warranty covers 12 months from the date of commissioning or 18 months from shipment, whichever comes first. Extended warranty packages are available. All major components (motors, PLC, inverters) are sourced from reputable brands.
Q: Can I visit your factory to see the line in operation? A: Yes, we welcome factory visits in Huzhou, Zhejiang. You can see a demo line running and discuss your requirements directly with our engineers. Contact our sales team to schedule.
Note: Specifications and configurations may vary based on final project requirements. All information is subject to change without notice. Please consult with our engineers for the latest technical data.
