Industrial Microwave Drying Machine for Chemical Powder Moisture Removal
Our Industrial Microwave Drying Machine is designed for efficient moisture removal from chemical powders, granules, crystals, and other industrial materials. By using advanced microwave heating technology, the system provides rapid and uniform drying, helping manufacturers improve production efficiency while reducing energy consumption.
The continuous conveyor design and intelligent PLC control system ensure stable operation, precise process control, and consistent product quality. The equipment can be customized to meet different material characteristics and production capacities.
Key Features
High-efficiency moisture removal
Continuous automatic drying
Uniform microwave heating
Short processing time
Energy-saving operation
PLC touch-screen intelligent control
Adjustable microwave power
Adjustable conveyor speed
Continuous industrial production
SUS304 stainless steel or customized contact materials
Easy operation and maintenance
OEM & ODM customization available
CE-compliant design available
Suitable Materials
This equipment is suitable for a wide range of non-flammable and non-explosive materials, including:
Chemical powders
Chemical granules
Crystalline chemicals
Pigments
Catalysts
Ceramic powders
Mineral powders
Inorganic salts
Functional materials
Battery raw materials
Industrial additives
Note: The suitability of microwave drying depends on the material's dielectric properties, moisture content, and safety requirements. Material testing is recommended before equipment selection.
Working Principle
Microwave energy penetrates the material and directly heats internal moisture, allowing water to evaporate rapidly from the inside out. Compared with conventional hot-air drying, this method offers faster drying, more uniform moisture distribution, and improved energy efficiency. The continuous conveyor system supports automated production for industrial applications.
Applications
Suitable for:
Chemical manufacturing plants
Fine chemical production
Mineral processing
Ceramic material processing
Battery material production
Industrial powder processing
Functional material manufacturing
Chemical raw material drying
Why Choose Our Microwave Dryer?
Factory-direct manufacturer with competitive pricing
Customized solutions for different materials and capacities
Advanced microwave drying technology
Stable continuous production
Professional engineering support
Installation guidance and operator training
One-year warranty
Lifetime technical support
Exported to customers worldwide
Technical Specifications
Machine Model |
GS-20HMV |
GS-40HMV |
GS-60HMV |
GS-100HMV |
GS-200HMV |
Work Frequency |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
Rated Apparent Power |
≤25KW |
≤50KW |
≤75KW |
≤120KW |
≤240KW |
Output Power |
≥20KW |
≥40KW |
≥60KW |
≥100KW |
≥200KW |
Dehydration Capacity |
16-20kg/hour |
30-40kg/hour |
48-60kg/hour |
80-100kg/hour |
160-200kg/hour |
Work Process Temperature |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
Cooling Type |
Water Cool/Air Cool |
Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool |
Work Time |
24h Continuously Work |
24h Continuously Work | 24h Continuously Work | 24h Continuously Work | 24h Continuously Work |
Operation |
PLC & Touch Screen |
PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen |
Feeding Inlet Height |
40-100mm |
40-100mm | 40-100mm | 40-100mm | 40-100mm |
Belt Height |
60-1000mm |
60-1000mm | 60-1000mm | 60-1000mm | 60-1000mm |
Belt Running Speed |
0-4.5m/min or Customized |
0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized |
Belt Width |
500±100mm |
800±100mm |
800±100mm |
1000±100mm |
1200±100mm |
Belt Material |
Teflon Material or Customized |
Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized |
Size |
8640×1220×2200mm |
10960×1500×2200mm |
13200×1500×2200mm |
15600×1700×2200mm |
22560×1900×2200mm |
Remark: Above parameter is for reference. All microwave dryer specific parameter need to be designed based on customer’s specific industrial request
FAQ
Q1: What chemical powders can this machine process?
It is suitable for many non-flammable, non-explosive chemical powders, granules, and industrial materials. Material evaluation is recommended before purchase.
Q2: Can the equipment be customized?
Yes. We can customize the capacity, microwave power, conveyor dimensions, and control system according to your production needs.
Q3: Does microwave drying improve production efficiency?
Yes. Microwave drying typically provides faster and more uniform moisture removal than conventional hot-air drying, depending on the material properties.
Q4: Do you provide OEM & ODM services?
Yes. We offer customized machine design, branding, voltage options, and complete production line solutions.
China Gspring Machine are the manufactuer of Industrial Microwave Dryer, we can supply different kinds of microwave drying machine, like batch microwave oven for lab use
or for small capacity industrial use, industrial automatic tunnel mircrowave dryer, vaccum dryer specially for food & pharma industry etc. We have more than 10 years
experience on export, export to all over the world, like USA, Canada, Russia, India, Sri Lanka, Turkey, Vietnam, Indonesia, Pakistan,Philippines, Brazil, Egypt, Czech, Singapore, Armenia, Iraq, Iran, Malaysia, Bangladesh, Mexico, Peru, Algeria, Poland, Thailand, Nepal, Azerbaijan etc.
