High Efficiency Industrial Microwave Dryer for Chemical Powder Drying & Sterilization
Improve Drying Efficiency for Chemical Powder with Advanced Industrial Microwave Technology
Our High Efficiency Industrial Microwave Dryer for Chemical Powder is specially designed for continuous drying, heating and sterilization of chemical materials.
Compared with traditional hot air drying equipment, industrial microwave drying technology provides:
✔ faster drying speed
✔ uniform internal heating
✔ better product quality
✔ energy saving
✔ lower labor cost
✔ continuous automatic production
This industrial microwave drying equipment is widely used for:
chemical powder
catalysts
mineral powder
ceramic powder
activated carbon
graphite powder
lithium battery materials
inorganic chemicals
pharmaceutical powder
fine chemical raw materials
Why choose industrial microwave drying equipment for chemical powder?
1. Fast drying from inside to outside
Microwave energy directly acts on moisture molecules.
The moisture evaporates rapidly inside the material and moves outward.
Advantages:
✔ shorten drying time
✔ improve production efficiency
✔ reduce waiting time
✔ suitable for continuous production line
2. Uniform heating and stable drying result
Traditional heating usually heats surface first.
Microwave heating penetrates the material evenly.
Benefits:
✔ reduce overheating
✔ avoid powder caking
✔ maintain particle quality
✔ improve final consistency
3. Energy-saving and lower operating cost
Microwave heating transfers energy directly to the product.
Less heat loss than traditional fuel heating.
Benefits:
✔ save electricity
✔ lower factory operating cost
✔ improve energy efficiency
✔ suitable for long-term industrial production
4. Intelligent PLC automatic control system
Machine can be customized with:
✔ PLC control
✔ touch screen
✔ automatic conveyor belt
✔ adjustable microwave power
✔ adjustable temperature
✔ adjustable conveyor speed
✔ automatic alarm system
Easy for operators and stable for mass production.
5. Food-grade SUS304 stainless steel structure
Machine body uses high-quality stainless steel.
Advantages:
✔ anti-corrosion
✔ durable
✔ easy cleaning
✔ stable operation
✔ long service life
Suitable industries
Chemical industry
Pharmaceutical factory
Battery material processing
Fine chemical powder processing
Mineral powder drying
Laboratory and industrial production
Microwave Application in Chemical Industry
1. Microwave-Assisted Synthesis: Microwaves are being used to accelerate organic chemical reactions, leading to more efficient synthetic routes. Such as glass fiber drying,
The water inside and outside the glass fiber is evenly drained, which enhances the bonding strength between the coating (silicone) and the glass fiber surface, except that,
still have cellulose, graphite
2. Energy Efficiency: Microwave heating is more energy-efficient than conventional heating methods, as it directly converts electromagnetic energy into heat within
certain materials. Such as quartz sand, Iron ore, copper ore, aluminum ore etc.
3. Process Intensification: The use of microwaves can lead to more sustainable industrial processes by reducing energy consumption, process time, and environmental
remediation associated with industrial processing, such as chemical powder, silicon carbide drying，Magnesium Carbonate, Silicon dioxide, lithium hydroxide etc. it can
achieve safe, energy-saving & friend environmentally.
4. Material Processing: Microwaves are used in the processing of various materials, including polymers, nanomaterials, and biomaterials. Such as drying of pigments,
dyes and pre forming of paste material.
We are the manufactuer of Industrial Microwave Dryer, we can supply different kinds of microwave drying machine, like batch microwave oven for lab use or for small
capacity industrial use, industrial automatic tunnel mircrowave dryer, vaccum dryer specially for food & pharma industry etc. We have more than 10 years experience
on export, export to all over the world, like USA, Canada, Russia, India, Sri Lanka, Turkey, Vietnam, Indonesia, Pakistan,Philippines, Brazil, Egypt, Czech, Singapore,
Armenia, Iraq, Iran, Malaysia, Bangladesh, Mexico, Peru, Algeria, Poland, Thailand, Nepal, Azerbaijan etc.
Technical Specifications
Machine Model |
GS-20HMV |
GS-40HMV |
GS-60HMV |
GS-100HMV |
GS-200HMV |
Work Frequency |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
Rated Apparent Power |
≤25KW |
≤50KW |
≤75KW |
≤120KW |
≤240KW |
Output Power |
≥20KW |
≥40KW |
≥60KW |
≥100KW |
≥200KW |
Dehydration Capacity |
16-20kg/hour |
30-40kg/hour |
48-60kg/hour |
80-100kg/hour |
160-200kg/hour |
Work Process Temperature |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
Cooling Type |
Water Cool/Air Cool |
Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool |
Work Time |
24h Continuously Work |
24h Continuously Work | 24h Continuously Work | 24h Continuously Work | 24h Continuously Work |
Operation |
PLC & Touch Screen |
PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen |
Feeding Inlet Height |
40-100mm |
40-100mm | 40-100mm | 40-100mm | 40-100mm |
Belt Height |
60-1000mm |
60-1000mm | 60-1000mm | 60-1000mm | 60-1000mm |
Belt Running Speed |
0-4.5m/min or Customized |
0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized |
Belt Width |
500±100mm |
800±100mm |
800±100mm |
1000±100mm |
1200±100mm |
Belt Material |
Teflon Material or Customized |
Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized |
Size |
8640×1220×2200mm |
10960×1500×2200mm |
13200×1500×2200mm |
15600×1700×2200mm |
22560×1900×2200mm |
Remark: Above parameter is for reference. All microwave dryer specific parameter need to be designed based on customer’s specific industrial request
Why buyers choose us on Goldsupplier
✔ factory direct price
✔ OEM / ODM support
✔ CE available
✔ export experience
✔ customized production line
✔ installation guidance
✔ engineer support
✔ fast delivery
✔ stable quality
✔ long-term technical service
Why buyers choose us on Goldsupplier
✔ factory direct price
✔ OEM / ODM support
✔ CE available
✔ export experience
✔ customized production line
✔ installation guidance
✔ engineer support
✔ fast delivery
✔ stable quality
✔ long-term technical service
Send Inquiry Now
Looking for a reliable industrial microwave dryer for chemical powder drying?
Please send us:
material name
moisture before drying
moisture after drying
required capacity per hour
available factory space
voltage requirement
We will recommend the most suitable microwave drying solution for your project.
