Help CenterCustomized High Ammonia Nitrogen Wastewater Treatment Equipment With Multi-Stage A/O and MBR Process
Product Spotlights
Related Products
-
Designed for Coking and Fertilizer Plants: High Ammonia Nitrogen Wastewater Treatment SystemUS$ 5280 - 585000MOQ: 1 Combo -
High Efficiency Ammonia Nitrogen Stripping Tower for Wastewater, Capacity 50m³/day, IP65 Control BoxUS$ 5280 - 585000MOQ: 1 Combo
-
High Ammonia Nitrogen Wastewater Treatment Equipment for Landfill Leachate and Petrochemical IndustryUS$ 5280 - 585000MOQ: 1 Combo
-
Industrial Grade High Ammonia Nitrogen Treatment System, 304SS, Flow Rate 30m³/h, PLC ControlUS$ 5280 - 585000MOQ: 1 Combo
-
1-Year Warranty and Free Installation Guidance for High Ammonia Nitrogen Wastewater Treatment EquipmentUS$ 5280 - 585000MOQ: 1 Combo
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. As a professional manufacturer since 2015, we specialize in advanced wastewater treatment solutions. Our Customized High Ammonia Nitrogen Wastewater Treatment Equipment with Multi-Stage A/O and MBR Process is designed to efficiently remove high concentrations of ammonia nitrogen and organic pollutants, ensuring effluent meets stringent discharge standards. This integrated system combines the advantages of multi-stage anoxic/oxic (A/O) biological treatment with membrane bioreactor (MBR) technology, offering a compact footprint, stable operation, and excellent solid-liquid separation.
Our equipment is widely used in industries such as petrochemical, pharmaceutical, landfill leachate, livestock breeding, and municipal wastewater treatment. With a factory area of 10,000-30,000 square meters and over 200 employees, we have the capacity to deliver customized solutions tailored to your specific wastewater characteristics and flow rates. We export to markets worldwide, including North America, Europe, Southeast Asia, and Africa.
Key Features and Technical Specifications:
- Multi-stage A/O process: Enhanced nitrification and denitrification for high ammonia nitrogen removal efficiency (up to 95%+).
- MBR module: High-quality hollow fiber or flat sheet membranes with long service life (3-5 years) and low fouling rate.
- Customizable design: Available in containerized, skid-mounted, or concrete tank configurations to suit your space and installation requirements.
- Fully automatic PLC control: Real-time monitoring of DO, pH, ORP, and flow; remote control and alarm functions.
- Low energy consumption: Optimized aeration and recirculation design reduces operating costs.
- Compact footprint: MBR replaces secondary sedimentation tank, saving up to 50% space compared to conventional processes.
- High quality effluent: SS < 5 mg/L, NH₃-N < 5 mg/L (adjustable per standards).
| Parameter | Value |
| Inlet NH₃-N concentration | 100-2000 mg/L (customizable) |
| Outlet NH₃-N concentration | < 10 mg/L (or meets local standards) |
| COD removal efficiency | > 90% |
| Operating temperature | 5-45 °C |
| Membrane material | PVDF (optional PTFE) |
| Design life | 15+ years |
Why Choose Our Equipment?
- Proven performance: Our systems have been successfully deployed in over 100 projects worldwide.
- Customization: We tailor every unit to your specific ammonia nitrogen load, flow rate, and discharge requirements.
- Comprehensive support: From design and manufacturing to installation, commissioning, and after-sales service.
- Certifications: Our factory is ISO9001, ISO14000, OHSAS18001 certified, ensuring quality and safety.
- Cost-effective: Optimized design reduces chemical and energy consumption.
Trusted by Global Clients
Qingdao Conqinphi Environmental Technology Group Co., Ltd. operates a modern factory spanning 10,000-30,000 square meters in Qingdao, Shandong, China. With an annual export value of US$10-50 million and a team of 201-300 skilled employees, we have extensive experience serving diverse markets including North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, and the Middle East. Our products comply with international standards, and we hold multiple certifications including HACCP, TL900, QS9000, SA8000, and more. We are committed to delivering reliable wastewater treatment solutions that help our clients achieve environmental compliance and operational efficiency. Contact us today to discuss your project and receive a customized quotation!
Frequently Asked Questions
-
Q: What is the typical treatment capacity of this equipment?
A: The capacity is fully customizable. We have designed systems ranging from 1 m³/h for small industrial sites to 1000 m³/h for large municipal plants. -
Q: Can the equipment handle fluctuating ammonia nitrogen loads?
A: Yes, the multi-stage A/O process with recirculation provides excellent buffering capacity. PLC control adjusts aeration and recirculation rates automatically to maintain stable performance. -
Q: What is the membrane cleaning method?
A: We offer both offline chemical cleaning (CIP) and online backwashing. Cleaning frequency depends on water quality, typically every 1-3 months. -
Q: Do you provide installation and commissioning services?
A: Yes, we can send engineers to your site for supervision or full turn-key installation. Remote technical support is also available. -
Q: What is the lead time for a customized system?
A: Typically 30-45 days after design approval, depending on complexity and order quantity. -
Q: Is the equipment suitable for cold climates?
A: We can provide insulation, heating systems, and indoor installation options to ensure reliable operation in low temperatures. -
Q: What certifications does the equipment meet?
A: Our manufacturing process is ISO9001, ISO14000, OHSAS18001 certified. We can also design to meet local discharge standards (e.g., EPA, EU directives). -
Q: Do you offer spare parts and after-sales support?
A: Yes, we maintain a stock of membranes, pumps, valves, and controllers. Our team provides 24/7 online support and quick spare part delivery.
