Help CenterTriple-effect Evaporation Unit for Wastewater Treatment, Zero Liquid Discharge, Customizable
Product Spotlights
Related Products
-
300t/d Sodium Chloride and Sodium Sulfate Triple-effect Evaporation SystemUS$ 5890 - 536900MOQ: 1 Combo -
Forced Circulation Three-Effect Evaporator for Enhanced Chemical ProcessingUS$ 790 - 96500MOQ: 1 Combo
-
Plate-Type Triple-Effect Evaporator for Optimal Heat Exchange PerformanceUS$ 5000 - 214000MOQ: 1 Combo
-
Triple-Effect Plate-Type Evaporator for Fine Chemicals Processing SystemUS$ 8790 - 254100MOQ: 1 Combo
-
High-Performance Plate-Type Evaporator for Fine Chemicals With Three EffectsUS$ 8790 - 254100MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd. (established in 2015) is a professional manufacturer specializing in advanced wastewater treatment solutions. Our Triple-effect Evaporation Unit for Wastewater Treatment is designed to achieve Zero Liquid Discharge (ZLD), combining high efficiency with customizable configurations to meet diverse industrial needs. With a factory area of 10,000–30,000 square meters and an annual export value exceeding US$10 million, we have supplied reliable evaporation systems to markets across North America, Europe, Southeast Asia, and the Middle East. This product represents our commitment to environmental sustainability and operational excellence.
The triple-effect design utilizes the vapor from the first effect as heating medium for the second effect, and so on, significantly reducing energy consumption compared to single-effect evaporators. This system is ideal for treating high-salinity wastewater, industrial brine, and chemical process streams, achieving up to 99% water recovery while leaving solid waste for disposal or reuse. Each unit is fully customizable — from material selection to control logic — ensuring seamless integration into your existing plant infrastructure.
Key Features & Technical Specifications
- Triple-effect energy efficiency — Consumes 30–50% less steam than single-effect systems, lowering operational costs.
- Zero Liquid Discharge capability — Produces high-quality distillate and dry solids, meeting stringent environmental regulations.
- Customizable design — Evaporation capacity, materials (SS304/316L), and automation level can be tailored to specific requirements.
- PLC automatic control — Touchscreen interface with real-time monitoring, alarms, and data logging for easy operation.
- Compact footprint — Modular skid-mounted design reduces installation space and site work.
- Wide application range — Suitable for chemical, pharmaceutical, food processing, landfill leachate, and oil & gas industries.
- Robust construction — Corrosion-resistant materials and anti-scaling design ensure long service life.
| Parameter | Standard Range | Remarks |
|---|---|---|
| Evaporation capacity | 500 – 5000 kg/h | Customizable above 5000 kg/h |
| Operating temperature | 80°C – 120°C (first effect) | Depends on feed composition |
| Steam consumption | 0.35 – 0.45 kg steam / kg water evaporated | Compared to 1.0 for single-effect |
| Power consumption | 50 – 200 kW | Including pumps and controls |
| Material of construction | SS304 / SS316L / Duplex | Option for high-chloride feed |
| Control system | PLC + HMI (Siemens/Mitsubishi) | Remote monitoring optional |
Advantages for Your Business
- ✅ Cost savings — Reduced energy consumption by up to 50% compared to conventional evaporators.
- ✅ Environmental compliance — Achieve ZLD and avoid costly wastewater discharge fees.
- ✅ Minimal maintenance — Anti-scaling design and easy-access inspection ports reduce downtime.
- ✅ Scalable solutions — Single units or multi-train configurations for large-scale projects.
- ✅ Global support — Our team provides installation supervision, commissioning, and after-sales service worldwide.
As a manufacturer with over 8 years of experience, we have delivered numerous triple-effect evaporation units to clients in North America, South America, Europe, Southeast Asia, Africa, and Oceania. Our factory is certified under ISO9001, ISO14000, OHSAS18001, and other quality management systems, ensuring every product meets rigorous standards. With a dedicated team of 201–300 employees and a strong export record, we are fully equipped to handle custom orders and large-scale projects.
Don’t let wastewater challenges hold back your production. Contact us today to discuss your specific requirements. Our engineers will work with you to design a triple-effect evaporation unit that delivers reliable ZLD performance, reduces your operating costs, and helps you meet environmental goals. Request a quote or technical datasheet now.
Frequently Asked Questions (FAQ)
-
Q: What types of wastewater can this unit treat?
A: It is suitable for high-salinity wastewater, brine, chemical process streams, landfill leachate, and many industrial effluents. The optimal feed composition should be evaluated by our engineers. -
Q: Can the evaporation capacity be customized?
A: Yes, the standard range is 500–5000 kg/h, but we can design larger capacities upon request. The unit is fully customizable. -
Q: What is the typical energy consumption compared to single-effect?
A: The triple-effect design reduces steam consumption by 40–50% — typically 0.35–0.45 kg steam per kg of water evaporated, versus 1.0 for single-effect. -
Q: What materials are used for construction?
A: Standard materials are SS304 or SS316L. For highly corrosive feed, we can use duplex stainless steel or other alloys. Please specify your feed composition. -
Q: How long does delivery take?
A: Typical lead time is 4–8 weeks depending on customization level. We can expedite for urgent projects. -
Q: Do you provide installation and commissioning support?
A: Yes, we offer on-site supervision, training, and after-sales service. Our team can also perform remote troubleshooting via the PLC system. -
Q: What certifications does your company hold?
A: We are certified under ISO9001, ISO14000, OHSAS18001, and other management systems. Product certifications are available upon request. -
Q: Is the unit suitable for Zero Liquid Discharge applications?
A: Absolutely. The system is designed to produce high-quality distillate and dry solids, enabling complete ZLD. It can be integrated with a crystallizer or dryer for final solid waste handling.
