Industrial Triple-effect Evaporation Unit, Fully Automatic, HMI Touch Screen, Standard Compliant
Product Spotlights
Industrial Triple-effect Evaporation Unit with fully automatic HMI touch screen control, achieving up to 60% energy savings via triple-effect design. Constructed from stainless steel, compliant with ISO standards, and suitable for wastewater, chemical, and food processing. Modular skid-mounted design reduces installation time. Backed by a manufacturer with 200+ employees and US$10M+ annual exports.
US$ 2490 - 87900
MOQ: 1 Combo
Key Specifications
Get Latest Price
Application:
Other, Wastewater treatment
Material:
Stainless Steel 316L/304
Capacity:
500-10000 L/h (customizable)
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
8 days
Related Products
-
Triple Effect Evaporator, 304/316L SS, 2000kg/h Evaporation Rate, 0.1MPa SteamUS$ 2490 - 87900MOQ: 1 Combo -
Triple-effect Evaporation Unit, Mill Test Report Provided, Factory Direct, Spare Parts IncludedUS$ 2490 - 87900MOQ: 1 Combo
-
Triple-effect Evaporation Unit for Wastewater Treatment, Zero Liquid Discharge, CustomizableUS$ 2490 - 87900MOQ: 1 Combo
-
300t/d Sodium Chloride and Sodium Sulfate Triple-effect Evaporation SystemUS$ 5890 - 536900MOQ: 1 Combo
-
Forced Circulation Three-Effect Evaporator for Enhanced Chemical ProcessingUS$ 790 - 96500MOQ: 1 Combo
Application
Other, Wastewater treatment
Material
Stainless Steel 316L/304
Capacity
500-10000 L/h (customizable)
Control System
HMI Touch Screen with PLC
Automation
Fully Automatic
Compliance
ISO9001, ISO14000, OHSAS18001
Power Supply
380V/50Hz (optional)
Steam Consumption
0.4-0.6 kg steam per kg water evaporated
Evaporation Temperature
60-100°C (adjustable)
Qingdao Conqinphi Environmental Technology Group Co., Ltd., a leading manufacturer established in 2015 with a factory spanning 10,000-30,000 square meters and an annual export value exceeding US$10 million, proudly presents our Industrial Triple-effect Evaporation Unit. This fully automatic system, equipped with an intuitive HMI touch screen, is designed to deliver exceptional energy efficiency, reduced operational costs, and consistent performance for demanding industrial applications. Whether you're concentrating wastewater, recovering valuable solvents, or processing heat-sensitive liquids, this unit ensures compliance with international standards while maximizing your return on investment.
Key Features & Technical Specifications
- Triple-effect Design: Utilizes three stages of evaporation to significantly reduce steam consumption — up to 60% less compared to single-effect systems. Each effect operates at a lower temperature, minimizing thermal degradation of sensitive products.
- Fully Automatic Operation: Integrated PLC with HMI touch screen allows for real-time monitoring of temperature, pressure, flow rate, and liquid level. Operators can set parameters, adjust alarms, and review historical data with a few taps.
- High Energy Efficiency: The system recovers latent heat from vapor in successive effects, typically achieving a steam economy of 2.5-3.0 kg water evaporated per kg steam.
- Stainless Steel Construction: All wetted parts are made of 316L or 304 stainless steel, ensuring corrosion resistance, hygiene, and long service life. Optional higher-grade alloys available upon request.
- Standard Compliance: Designed and manufactured in accordance with ISO9001, ISO14000, and OHSAS18001 standards, as well as applicable ASME and GB150 codes. The unit meets stringent safety and environmental regulations.
- Modular & Compact Footprint: Pre-assembled skid-mounted design reduces installation time and space requirements. Easy to integrate into existing production lines.
- Adaptable to Multiple Industries: Ideal for wastewater treatment, chemical concentration, pharmaceutical extraction, food & beverage concentration, and zero liquid discharge (ZLD) systems.
Technical Parameters (Standard Model)
| Parameter | Value |
| Evaporation Capacity | 500 – 10,000 L/h (customizable) |
| Steam Pressure (Inlet) | 0.3 – 0.8 MPa |
| Evaporation Temperature | 60 – 100°C (adjustable per effect) |
| Material of Construction | SS316L / SS304 (wetted parts) |
| Control Interface | 7-inch HMI Touch Screen with PLC |
| Power Supply | 380V, 50Hz, 3-phase (other voltages available) |
| Steam Consumption | 0.4 – 0.6 kg steam per kg water evaporated |
| Cooling Water Requirement | 20 – 40 m³/h (depending on capacity) |
Customer Benefits
- Lower Operating Costs: The triple-effect design reduces steam and cooling water consumption, translating directly into lower utility bills.
- Minimal Operator Training: The HMI touch screen provides a user-friendly interface with clear visualizations, alarms, and auto-start/stop sequences. Operators can be trained in hours.
- Consistent Product Quality: Precise temperature and pressure control prevent overheating and fouling, ensuring consistent concentration or recovery of valuable materials.
- Reduced Downtime: Automatic cleaning cycles (CIP) and self-diagnostic features help maintain optimal performance and extend equipment life.
- Scalability: Our modular design allows for future expansion or integration with other treatment units such as MVR evaporators or crystallizers.
Trust & Reliability
With over 200 skilled employees and a factory spanning 10,000-30,000 square meters, Qingdao Conqinphi Environmental Technology Group has delivered hundreds of evaporation systems to clients across North America, Europe, Southeast Asia, and beyond. Our annual export value of US$10 million to US$50 million reflects our commitment to quality and customer satisfaction. We hold multiple certifications including ISO9001, ISO14000, OHSAS18001, HACCP, and others, ensuring every unit meets rigorous international standards. Our team provides comprehensive after-sales support, including installation guidance, commissioning, and remote troubleshooting. Choose Conqinphi for a reliable partner in your environmental and process solutions.
Frequently Asked Questions
-
Q: What types of feed liquids can be processed?
A: This unit is suitable for aqueous solutions with low to medium viscosity, including wastewater, chemical solutions, food extracts, and pharmaceutical intermediates. For highly viscous or fouling liquids, we offer customized designs with forced circulation or scraped surface options. -
Q: How often is maintenance required?
A: Routine maintenance includes checking seals, cleaning heat exchanger surfaces, and verifying instrument calibration. The system is designed for continuous operation; we recommend a comprehensive inspection every 3-6 months. Automatic CIP cycles can be programmed to reduce manual cleaning. -
Q: Can the unit be integrated with existing MVR or crystallizer systems?
A: Yes, our triple-effect evaporator can be used as a pre-concentrator before MVR or as a standalone unit. We provide piping and control integration services upon request. -
Q: What is the typical delivery time?
A: For standard models, delivery is 30-45 days after order confirmation. Customized units may require 60-90 days depending on complexity. -
Q: Is the HMI touch screen available in multiple languages?
A: Yes, the interface supports English, Chinese, Spanish, and other languages. We can add additional languages as needed. -
Q: What safety features are included?
A: The system includes over-temperature protection, high-pressure alarms, emergency stop, leak detection, and automatic shutdown on abnormal conditions. All electrical components are rated for industrial environments. -
Q: Can you provide a pilot test before purchase?
A: Absolutely. We offer on-site pilot testing or send a mobile test unit to your facility. Contact our sales team to schedule a trial.
Contact us today to discuss your specific requirements. Our engineers will work with you to design the optimal evaporation solution for your process, backed by the strength of a reliable manufacturer with global reach.
