Product Introduction
This flotation cell for high recovery flotation process is a high-precision beneficiation separation equipment tailored for scenarios that require extremely high mineral recovery rate. It adopts optimized micro-bubble generation structure and precise flow field control design, which can efficiently capture fine-grained target minerals that are difficult to recover by ordinary equipment. It can be widely used in the flotation process of precious metals, rare metals and fine-grained non-ferrous metal ores, effectively increasing the overall concentrate recovery rate of the beneficiation plant and maximizing the resource utilization rate.
Working Principle
The specially designed stirring and aeration system generates a large number of uniformly distributed micro-bubbles with a diameter of less than 0.5mm. The precise flow field control structure makes the pulp in the tank form a stable and gentle ascending flow, which greatly prolongs the contact time between fine-grained target mineral particles and bubbles. The mineral particles are fully attached to the surface of micro-bubbles and rise to form a stable high-concentration froth layer. The special froth scraping device completely collects the froth carrying target minerals, avoiding the loss of fine-grained useful minerals in the tailings.
Core Features
This product has multiple targeted advantages for high recovery flotation process. The micro-bubble generation technology significantly improves the capture efficiency of fine-grained target minerals, and the recovery rate can be increased by 3% to 8% compared with ordinary flotation cells. The optimized tank structure reduces the pulp turbulence, avoiding the falling off of attached mineral particles. It can be seamlessly connected with the existing high recovery flotation process flow without large transformation. The high recovery performance directly increases the total concentrate output of the concentrator, bringing considerable additional economic benefits to the mine.
Technical Specifications
Category |
Model |
Effective Volume |
Capacity |
Impeller |
Impeller RPM Motor Power |
(kW)-Agitating |
Motor Power |
Single Weight (t) |
XJK type |
XJK-0.35 |
0.35 |
0.18-0.4 |
300 |
480 |
1.5 |
0.75 |
0.6 |
XJK-0.62 |
0.3-0.9 |
350 |
400 |
3 |
1.1 |
0.9 |
||
XJK-1.1 |
0.6-1.6 |
500 |
330 |
5.5 |
1.1 |
1.3 |
||
XJK-2.8 |
1.5-3.5 |
600 |
280 |
11 |
1.5 |
2.5 |
||
XJK-5.8 |
5.8 |
5-7 |
750 |
240 |
15 |
1.5 |
3.6 |
|
SF type Flotation |
SF-0.37 |
0.37 |
0.2-0.4 |
300 |
352-442 |
1.5 |
0.55 |
0.5 |
SF-0.65 |
0.65 |
0.3-1.0 |
350 |
336 |
3 |
1.1 |
1 |
|
SF-1.2 |
1.2 |
0.6-1.6 |
450 |
298 |
5.5 |
1.1 |
1.5 |
|
SF-2.8 |
2.8 |
1.5-3.5 |
550 |
268 |
11 |
1.5 |
2.3 |
|
SF-4 |
4 |
2-4 |
650 |
237 |
15 |
2.2 |
2.8 |
|
SF-8 |
8 |
4-8 |
760 |
191 |
30 |
2.2 |
4.3 |
|
SF-10 |
10 |
5-10 |
760 |
191 |
30 |
3 |
4.6 |
|
SF-16 |
16 |
6-16 |
850 |
180 |
45 |
3 |
7.8 |
|
SF-20 |
20 |
8-20 |
730 |
186 |
55 |
3 |
9.8 |
|
| JJF type Flotation machine | JJF-2 |
2 |
1-3 |
370 |
400 |
11 |
1.1 |
1.9 |
JJF-4 |
4 |
2-4 |
410 |
305 |
15 |
1.5 |
2.3 |
|
JJF-8 |
8 |
4-8 |
540 |
233 |
22 |
2.2 |
4.5 |
|
JJF-10 |
10 |
5-10 |
540 |
233 |
22 |
2.2 |
4.9 |
|
JJF-16 |
16 |
5-16 |
700 |
180 |
37 |
2.2 |
8.2 |
|
JJF-20 |
20 |
5-20 |
730 |
180 |
37 |
2.2 |
10.5 |
