Deqing Leixin Coating Equipment Co., Ltd., a professional manufacturer established in 2011, brings you the Automatic Discharge Small Cyclone Stainless Steel Powder Collector – a compact yet highly efficient solution for industrial dust recovery. Designed to automatically separate and discharge fine powders, this cyclone collector is crafted from premium stainless steel to withstand harsh operating conditions while delivering consistent performance. Whether you are in powder coating, chemical processing, or food production, this unit helps you reclaim valuable materials and maintain a clean working environment.
Key Features & Technical Highlights
Automatic Discharge System: Equipped with a timed or sensor-controlled discharge valve, the collector automatically empties accumulated powder without manual intervention, reducing labour costs and downtime.
Stainless Steel Construction: Made from high-quality 304 or optional 316 stainless steel, ensuring excellent corrosion resistance, longevity, and food-grade compatibility when required.
Cyclone Separation Principle: Uses centrifugal force to separate solid particles from air streams with high efficiency (typically >95% for particles >10 µm), ideal for fine powder recovery.
Compact Footprint: Small cyclone design saves valuable floor space while still handling moderate airflow volumes, perfect for integration into existing production lines.
Low Maintenance: No moving parts inside the cyclone body; the automatic valve requires minimal upkeep. All stainless steel surfaces are easy to clean.
Versatile Applications: Suitable for dust recovery in paint powder, pharmaceutical powders, metal dust, wood pellets, and many other dry granular materials.
Technical Specifications (Typical Model)
| Parameter | Value |
|---|---|
| Airflow Capacity | 100 – 500 m³/h (customizable) |
| Separation Efficiency | > 95% for particles > 10 µm |
| Pressure Drop | 800 – 1500 Pa |
| Material | Stainless Steel 304 (316 optional) |
| Discharge Outlet Diameter | 100 – 200 mm (customizable) |
| Overall Dimensions (L×W×H) | 600×400×800 mm (typical, varies per model) |
Advantages for Your Business
Cost Savings: Recover valuable powder for reuse, reduce waste disposal costs, and minimize raw material consumption.
Enhanced Workplace Safety: Keeps airborne dust under control, reducing explosion risks and improving air quality for operators.
Increased Productivity: Automatic discharge eliminates manual cleaning cycles, allowing continuous operation.
Eco-Friendly: Lower dust emission to the environment, helping your facility meet local environmental regulations.
Easy Integration: Compact design fits easily into new or existing dust collection systems; can be mounted on a stand or directly attached to machinery.
Why Choose Deqing Leixin?
As a dedicated manufacturer with over a decade of experience, our factory spans 1,000–3,000 m² and is staffed by a skilled team of 51–100 employees. We achieve an annual export value of US$1 million to US$1.5 million, serving markets across North America, South America, Europe, Asia, Africa, and Oceania. Our products are ISO9001 certified, ensuring consistent quality and reliability. We ship from the major ports of Ningbo and Shanghai, offering competitive lead times and comprehensive after-sales support.
Our Automatic Discharge Small Cyclone Stainless Steel Powder Collector is built with precision and backed by years of engineering expertise. We welcome OEM/ODM requirements and offer customizations to meet your specific process needs. Contact us today for a quote or technical consultation – let us help you optimize your dust recovery system.
Frequently Asked Questions (FAQ)
Q1: What particle size can this cyclone collector handle efficiently?
A1: The cyclone is designed to achieve >95% separation efficiency for particles larger than 10 microns. For finer particles (sub-micron), a bag filter or cartridge filter may be used as a secondary stage.
Q2: Can it handle sticky or hygroscopic powders?
A2: While the stainless steel surface is smooth and resistant to corrosion, sticky powders may cause build-up. We recommend using this collector for dry, free-flowing powders. Optional coating or polishing is available upon request.
Q3: How does the automatic discharge valve work?
A3: Our standard design uses a pneumatic or electric rotary valve that opens periodically (time-controlled) or when a level sensor detects accumulated powder. The valve seals tightly when closed to maintain system pressure.
Q4: What maintenance is required?
A4: Minimal maintenance is needed – inspect the discharge valve seals periodically, and clean the cyclone body if processing very fine or abrasive materials. No internal moving parts simplifies upkeep.
Q5: Can you customize the size or connection ports?
A5: Yes, we offer customizable dimensions, inlet/outlet diameters, and flange types to match your existing ductwork. Please provide your specific airflow requirements and space constraints.
Q6: Is this collector suitable for explosive dust?
A6: Our standard model is not ATEX-certified. For combustible dust applications, we can design with explosion-relief vents and grounding options. Please discuss your safety requirements with our engineering team.
Q7: What is the typical lead time?
A7: For standard models, lead time is around 15–30 working days. Custom orders may require additional time depending on complexity. We ship from Ningbo or Shanghai.
Q8: Do you provide installation or technical support?
A8: Yes, we offer installation drawings, manuals, and online technical support. On-site guidance can be arranged upon request.
