Deqing Leixin Coating Equipment Co., Ltd. has been manufacturing high-performance industrial separation equipment since 2011. Our Cyclone Recovery Equipment Centrifugal Separator is designed specifically for solid particle material recycling and dust removal in manufacturing, mining, and coating industries. With a factory size of 1,000–3,000 square meters and ISO9001 certified quality management, we deliver reliable, efficient, and cost-effective solutions that help our customers reduce waste, improve air quality, and recover valuable materials. This cyclone separator uses centrifugal force to separate solid particles from gas streams, offering a simple yet robust design with minimal maintenance requirements.
Our centrifugal separator is constructed from high-quality materials such as carbon steel or stainless steel (optional) to withstand abrasive and corrosive environments. It features a tangential inlet that creates a strong vortex, throwing heavier particles to the outer wall where they spiral down into a collection hopper, while cleaned gas exits through the top outlet. This equipment is ideal for recycling metal powders, plastic granules, wood dust, cement, and other dry particulate materials. Depending on particle size distribution, separation efficiency can reach up to 99%, significantly reducing downstream filter load and extending baghouse or cartridge filter life.
| Parameter | Specification |
|---|---|
| Model Range | LX-CYC-100 to LX-CYC-2000 (customizable) |
| Air Volume Capacity | 500 – 50,000 m³/h |
| Pressure Drop | 500 – 1500 Pa (depends on design) |
| Particle Size Range | 5 – 2000 microns |
| Operating Temperature | Standard -20°C to 80°C; high-temp version up to 200°C |
| Material Options | Carbon steel (painted), SS304, SS316L, or lined |
- High Separation Efficiency – Centrifugal forces up to 3000G ensure effective removal of fine and coarse particles.
- Low Maintenance – No moving parts, minimal wear, and easy access for cleaning and inspection.
- Space-Saving Design – Compact footprint compared to baghouse or electrostatic precipitators.
- Energy Efficient – Low pressure drop reduces fan energy consumption.
- Versatile Application – Suitable for recycling metal powders, wood dust, plastic granules, mineral powders, and more.
- Customizable Options – Inlet/outlet sizes, material grade, anti-abrasion lining, explosion-proof design available.
Our cyclone separator benefits your operation by recovering valuable materials that would otherwise be lost. For example, in powder coating manufacturing, it recovers overspray powder for reuse, saving up to 30% material costs. In woodworking, it collects sawdust for biomass fuel, reducing waste disposal fees. The device also protects downstream equipment (e.g., fans, scrubbers) from particle erosion and extends their service life. With port options of Ningbo and Shanghai, we export globally to North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East, serving industries from chemical processing to food production.
Trust Deqing Leixin Coating Equipment Co., Ltd. for your solid particle recovery and dust removal needs. As a manufacturer with ISO9001 certification and annual export value between US$1 million and US$1.5 million, we have supplied reliable equipment to over 15 international markets since 2011. Our engineering team can tailor the cyclone separator to your specific particle characteristics and process conditions. We provide comprehensive after-sales support, including installation guidance and spare parts availability. Contact us today for a quote or technical consultation – experience the perfect balance of performance, durability, and value.
Frequently Asked Questions
Q1: What is the typical separation efficiency of this cyclone separator?
A1: For particles larger than 10 microns, efficiency typically exceeds 95%. For particles between 5–10 microns, it can reach 80–95% depending on design and flow conditions. Fine particles below 5 microns may require a secondary filtration system.
Q2: Can this cyclone separator handle sticky or moist materials?
A2: Standard design is for dry, free-flowing materials. For sticky or moist particles, we recommend an optional anti-abrasion lining or heated shell to prevent buildup. Please consult our engineers for material compatibility assessment.
Q3: What maintenance is required?
A3: Regular inspection of the cone and dust discharge valve for wear is recommended every 3–6 months. No lubrication or moving parts maintenance is needed. Occasional cleaning may be required if material build-up occurs.
Q4: Can I use this separator as a standalone dust collector?
A4: Yes, it can serve as a primary dust collector for coarse particles. For fine dust or strict emission standards, it is often used as a pre-collector before a baghouse or cartridge filter.
Q5: What sizes are available?
A5: We offer standard models from 100 mm to 2000 mm diameter. Custom sizes are available upon request to match your airflow and space requirements.
Q6: Do you provide installation and commissioning support?
A6: Yes, we provide technical documentation and online/on-site guidance for installation and commissioning. Spare parts and wear components are also available.
Q7: Is the equipment certified?
A7: Our manufacturing facility is ISO9001 certified. The cyclone separator itself meets general industrial standards. Additional certifications (e.g., ATEX for explosive dust) can be arranged upon request.
Q8: What is the typical lead time?
A8: Standard models: 15–25 working days. Custom designs: 30–45 working days, depending on complexity and order quantity.
