Help CenterEnergy Efficient MVR Evaporator System With 1000kg/hr Capacity
Product Spotlights
Related Products
-
Customizable Double-effect MVR Evaporator for Specific Industrial Effluent VolumeUS$ 7420 - 950000MOQ: 5 Combos -
Double-effect MVR Evaporator With Automatic Control for High-Salinity Industrial Brine TreatmentUS$ 7420 - 950000MOQ: 5 Combos
-
Double-effect MVR Evaporator System With Mill Test Report and 1-Year WarrantyUS$ 7420 - 950000MOQ: 5 Combos
-
Energy-Efficient Double-effect MVR Evaporator With Heat Recovery for Food ProcessingUS$ 7420 - 950000MOQ: 5 Combos
-
Corrosion-Resistant Titanium Double-effect MVR Evaporator for Chemical ConcentrationUS$ 7420 - 950000MOQ: 5 Combos
As a leading manufacturer in environmental technology, Qingdao Conqinphi Environmental Technology Group is proud to present our advanced Energy Efficient MVR Evaporator System. With a robust production facility spanning 10,000-30,000 square meters and over 200 skilled employees, we engineer solutions that address the critical needs of modern industry: reducing operational costs and minimizing environmental impact. Our MVR system, with a standard capacity of 1000kg/hr, represents a significant leap in evaporation technology, offering unparalleled energy savings and reliable performance for clients across North America, South America, Europe, Asia, and beyond.
This system is designed for businesses seeking to optimize their liquid concentration or wastewater treatment processes. By harnessing the principle of Mechanical Vapor Recompression, it recycles latent heat, drastically cutting down on energy consumption compared to traditional multi-effect or thermal evaporators. For a company like ours, with a strong export value and a commitment to quality management systems, delivering such a high-efficiency, cost-effective solution is at the core of our mission.
Core Product Features & Technical Advantages:
- Superior Energy Efficiency: The MVR (Mechanical Vapor Recompression) technology is the heart of this system. A compressor recompresses the vapor generated from the boiling liquid, raising its temperature and pressure so it can be reused as the heating medium. This closed-loop cycle typically reduces energy consumption by 60-90% compared to single-effect evaporators.
- High Capacity & Compact Design: Engineered for a continuous processing capacity of 1000 kg of water evaporation per hour, this system delivers high throughput in a relatively compact footprint, saving valuable factory floor space.
-
Advanced Automation & Control: The system is integrated with a sophisticated PLC (Programmable Logic Controller) and a user-friendly Touchscreen HMI (Human-Machine Interface). This allows for:
- Precise control over temperature, pressure, and flow rates.
- Real-time monitoring of system performance and energy usage.
- Automatic operation with recipe management and data logging.
- Remote access capabilities for supervision and troubleshooting.
- Robust Construction & Corrosion Resistance: Critical components in contact with the process fluid, such as the evaporator body, heat exchanger tubes, and separator, are constructed from high-grade stainless steel (316L or 304). This ensures exceptional durability and resistance to corrosion from a wide range of industrial feedstocks, including aggressive wastewater and food products.
-
Versatile Application Scope: This MVR evaporator is not a one-trick solution. It is expertly designed to handle diverse applications, providing tangible benefits across sectors:
- Wastewater Treatment & ZLD (Zero Liquid Discharge): Concentrates industrial wastewater (e.g., from textiles, pharmaceuticals, chemicals) to reduce disposal volumes and costs, facilitating water recovery.
- Food & Beverage Industry: Gently concentrates fruit juices, dairy products (whey), sugar syrups, and tea extracts while preserving heat-sensitive nutrients and flavors due to lower operating temperatures.
- Chemical & Pharmaceutical Processing: Precisely concentrates chemical solutions, recovers valuable solvents, and produces high-purity water.
- Low Operating & Maintenance Costs: The drastic reduction in steam or cooling water requirements translates directly into lower utility bills. The simple, robust design with minimal moving parts (primarily the compressor) also leads to reduced maintenance needs and downtime.
Key Technical Specifications:
| Parameter | Specification | Notes |
| Standard Evaporation Capacity | 1000 kg/hr | Water evaporation basis |
| Energy Source | Electricity (for compressor & pumps) | Steam-heated versions available |
| Compressor Type | Centrifugal or Rotary (customizable) | Selected based on duty and vapor properties |
| Operating Temperature Range | 40°C - 100°C | Lower temperatures protect heat-sensitive products |
| Final Concentrate Solids | Up to 40-60% (depending on feed) | Highly customizable |
| Control System | PLC + Touchscreen HMI | Standard configuration |
| Main Construction Material | Stainless Steel 304/316L | Other materials available upon request |
Benefits for Your Business:
- Substantial Cost Reduction: Slash your energy bills by reusing vapor heat instead of consuming fresh steam or fuel.
- Enhanced Sustainability Profile: Lower energy consumption means a smaller carbon footprint, aligning with corporate environmental goals.
- Improved Process Reliability: Automated, continuous operation ensures consistent product quality and output.
- Reduced Waste Disposal Costs: Concentrate wastewater to a smaller volume, dramatically cutting hauling and treatment expenses.
- Product Quality Preservation: Gentle evaporation at lower temperatures is ideal for food, pharmaceutical, and sensitive chemical applications.
Choosing Qingdao Conqinphi means partnering with a manufacturer that has demonstrated global reach and a solid foundation. Our annual export value and presence in markets from North America to Oceania underscore the international trust in our technology. Operating from a major port city like Qingdao ensures smooth and efficient logistics for your order. We understand that every industrial process is unique. Therefore, our standard 1000kg/hr MVR system serves as an excellent base, which we can extensively customize in terms of materials, capacity scaling, automation level, and integration with your existing plant to deliver a perfect fit for your specific operational challenges and goals.
Frequently Asked Questions (FAQ):
-
Q: How does the MVR technology achieve such high energy efficiency?
A: MVR systems use a compressor to mechanically recompress the vapor produced during evaporation. This increases the vapor's temperature and pressure, allowing it to be cycled back as the heating steam for the same process. This reuse of latent heat eliminates the need for a continuous external steam supply, which is the primary source of energy consumption in traditional evaporators. -
Q: Is the 1000kg/hr capacity fixed, or can it be adjusted for my needs?
A: The 1000kg/hr is a standard rated capacity. We design and manufacture MVR evaporators across a wide range of capacities. We can scale the system up or down based on your specific feed flow rate and concentration requirements. Please provide your process details for a tailored solution. -
Q: What kind of maintenance does the compressor require?
A: The compressor is a key component. We typically use reliable, industrial-grade compressors (centrifugal or rotary) designed for continuous duty. Maintenance generally involves routine checks of lubrication, vibration, and seals as per the manufacturer's schedule, which is straightforward and minimizes downtime. -
Q: Can this system handle corrosive or scaling feed liquids?
A: Yes, but it requires proper design. We select corrosion-resistant materials like 316L stainless steel or higher alloys for aggressive feeds. For scaling tendencies, we integrate anti-scale strategies such as optimized heat exchanger design, pretreatment options, or automated cleaning-in-place (CIP) systems to manage fouling. -
Q: What is the typical payback period for investing in an MVR evaporator?
A: The payback period varies based on your local energy costs, current evaporation expenses, and system utilization. Due to the dramatic energy savings, many of our clients report a payback period of 1 to 3 years, making it a financially sound investment. -
Q: Do you provide installation and commissioning services?
A> Yes, we offer comprehensive support. Our services can include detailed installation drawings, supervision of on-site assembly, commissioning of the system, and operator training to ensure a smooth start-up and optimal performance. -
Q: How does the control system ensure stable operation?
A: The PLC-based control system continuously monitors critical parameters (temperature, pressure, levels, flow). It automatically adjusts the compressor speed, pump rates, and valves to maintain setpoints, ensuring stable evaporation conditions even if the feed composition fluctuates slightly. -
Q: Are spare parts readily available?
A> We maintain an inventory of common spare parts and can provide a recommended spare parts list upon purchase. For major components like the compressor, we source from reputable suppliers with global service networks to ensure parts availability.
In conclusion, our Energy Efficient MVR Evaporator System is more than just equipment; it's a strategic investment towards operational excellence and environmental responsibility. Backed by our company's established manufacturing prowess, quality-focused ethos, and proven track record in serving a diverse global clientele, you can be confident in the performance and reliability of our solution. Take the first step towards transforming your concentration process. Contact us today to discuss your application, request a detailed proposal, or arrange a virtual demonstration. Let our engineering team show you how the Conqinphi MVR difference can benefit your bottom line and your sustainability goals.
