Help CenterWater-Cooled High Power Charging (HPC) Cable 700A 1500V DC for EV Fast Charging
Product Spotlights
• High current-carrying capacity and superior temperature rise performance, significantly enhancing charging efficiency
• No risk of bursting, ensuring safety and reliability
• Fully certified to meet global cable standards across multiple regions
• Tailored liquid-cooled ultra-fast charging solutions available to meet specific customer requirements
Related Products
| Standard | Specifications |
Outer diameter of twisted main core wire conductor |
Reference return pipe specifications (customised to client requirements) |
Main conductor resistance |
Reference Current |
Finished external diameter |
Packaging |
| UL2263 | 4x3AWG+9AWG |
8.9 Ref. |
Φ4*6 |
≤0.78 |
650-700A |
Structure designed to meet standards and customer requirements |
As per the order or as agreed |
|
4x10mm2+Earth wire（6-25）+Auxiliary Source+Nx（0.5w-2.5）+Return pipe（Copper-clad water pipes）
|
8.1 Ref. |
Φ4*6 |
≤1.91 |
250-300A |
|||
4x10mm2+Earth wire（6-25）+Auxiliary Source+Nx（0.5w-2.5）+Return pipe（Isolation-type） |
4.2 Ref. |
Φ4*6 |
≤0.78 |
200-250A |
|||
4x20mm2+Earth wire（6-25）+Auxiliary Source+Nx（0.5w-2.5）+Return pipe（Copper-clad water pipes） |
8.6 Ref. |
Φ4*6 |
≤0.92 |
500-600A |
|||
| IEC 62893/ CQC1147 | 4x25mm2+Earth wire（6-25）+Auxiliary Source+Nx（0.5w-2.5）+Return pipe（Copper-clad water pipes） |
9.5 Ref. |
Φ4*6 |
≤0.78 |
600-700A |
||
4x25mm2+Earth wire（6-25）+Auxiliary Source+Nx（0.5w-2.5）+Return pipe（Isolation-type） |
6.7 Ref. |
Φ4*6 |
≤0.78 |
500-600A |
|||
4x35mm2+Earth wire（6-25）+Auxiliary Source+Nx（0.5w-2.5）+Return pipe（Copper-clad water pipes） |
10.5 Ref. |
Φ4*6 |
≤0.554 |
700A-800A |
|||
4x50mm2+Earth wire（6-25）+Auxiliary Source+Nx（0.5w-2.5）+Return pipe（Copper-clad water pipes） |
13.1 Ref. |
Φ6*8 |
≤0.386 |
900A-1000A |
