Model: PNI13104
Type: X/Y-axis magnetic sensor
Measurement range: +/-1100uT
Resolution: 0.015uT
Linearity: 0.60%
Power supply: 3/5V
Operating current: 0.5mA
Operating temperature: -40~+85℃
Communication interface: N/A
Size: 6×2.1×2.21mm
PNI Sen-XY is a Z-axis magnetic measurement sensor designed for vertical installation on a PCB board, which can be combined with the Z-axis magnetic sensor Sen-Z to form a 3-axis/3-dimensional magnetic solution. For most applications, the PNI magnetic inductive sensor S primarily serves as the sensing element of the measurement circuit (LR relaxation oscillation circuit), where the magnitude of the sensing quantity is proportional to the magnetic field parallel to the sensor's measurement axis. The frequency of the oscillation circuit driven by an ASIC varies with different magnetic fields. By measuring the time of a specific number of oscillation cycles, the magnitude of the measured magnetic field can be deduced.
The unique advantages of the measurement method employed by PNI magnetic sensors include low power consumption, high resolution, no hysteresis, digital output, low temperature drift, and minimal interference from environmental electrical noise.
Main parameters:
Power supply: typically 3.3V
Power consumption: 0.5mA (max)
Resolution: 0.015 uT
Measurement range: +/-11 Gauss
Operating temperature: -40~85
Size: 6*2.21*2.10 mm (SEN-XY)
