As a leading manufacturer with over eight years of expertise, Qingdao Conqinphi Environmental Technology Group is proud to present our advanced Three-Effect Continuous Evaporation Crystallizer with Double Jacket Heating. Engineered for high-volume industrial processing, this system is designed to deliver exceptional efficiency in separating solvents from solutes, producing high-purity crystals with remarkable energy savings. Our commitment to innovation and robust manufacturing, backed by a 10,000-30,000 sqm facility and a dedicated team of over 200 professionals, ensures that this crystallizer meets the rigorous demands of global markets, from North America to Southeast Asia.
This system represents a significant leap in crystallization technology. The three-effect continuous design maximizes thermal efficiency by reusing vapor from one effect to heat the next, drastically reducing steam consumption. Coupled with the double jacket heating method, it provides uniform and controllable heat transfer, preventing localized overheating and ensuring consistent crystal quality. The 2000L per hour capacity makes it an ideal solution for medium to large-scale production lines seeking to enhance output while minimizing operational costs.
Core Technical Specifications & Advantages:
- High-Efficiency Design: The triple-effect configuration can achieve steam economies significantly higher than single or double-effect units, often reducing energy requirements by over 60%.
- Superior Heating Control: The double jacket allows for precise temperature management of the crystallizing mass, which is crucial for controlling crystal size distribution (CSD) and preventing scaling or fouling.
- Continuous Operation: Enables non-stop processing, leading to higher throughput, more stable product quality, and reduced labor costs compared to batch systems.
- Robust Construction: Typically fabricated from corrosion-resistant stainless steel (SS304 or SS316L), ensuring longevity and compliance with hygiene standards for food, pharmaceutical, and chemical applications.
- Automation Ready: Can be integrated with PLC and SCADA systems for automated control of parameters like temperature, pressure, vacuum, and feed rate, enhancing reproducibility and safety.
The benefits for your operation are substantial. You will achieve lower energy consumption per unit of product, higher purity crystalline output, and increased overall plant productivity. The system's design minimizes downtime for cleaning and maintenance, directly impacting your bottom line.
| Parameter | Specification |
|---|---|
| Model | CEC-3E-2000 (Standard) |
| Design Capacity | 2000 L/H (Evaporation Rate) |
| Number of Effects | 3 (Continuous) |
| Heating System | Double Jacket with Steam/Thermal Oil |
| Operating Pressure | Vacuum to Slightly Positive (Customizable) |
| Main Material | Stainless Steel 304/316L |
| Control Interface | Touch Screen PLC Panel (Optional) |
Trust in our proven track record. Qingdao Conqinphi exports to five continents, supported by an annual export value in the range of US$10-50 million, demonstrating reliable international logistics and service. Our manufacturing processes are guided by a comprehensive quality management system. We invite you to leverage our expertise to optimize your crystallization process. Contact us today to discuss how this high-capacity, energy-efficient crystallizer can be tailored to meet your specific production goals and drive your operational success.
Frequently Asked Questions (FAQ):
-
Q: What are the primary industries that use this type of crystallizer?
A: This equipment is widely used in the chemical industry for salt production, in pharmaceuticals for active ingredient isolation, in food processing for sugar or lactose crystallization, and in environmental treatment for zero-liquid discharge (ZLD) systems. -
Q: How does the "three-effect" design contribute to energy savings?
A: In a multi-effect system, the vapor generated from the first evaporation effect is used as the heating source for the second effect, and so on. This cascading reuse of latent heat dramatically reduces the total fresh steam required, making it highly energy-efficient. -
Q: Can the system handle heat-sensitive materials?
A: Yes. The operation can be conducted under vacuum, which lowers the boiling point of the solvent. Combined with the precise temperature control of the double jacket, it is suitable for processing materials that degrade at higher temperatures. -
Q: Is the 2000L/H capacity fixed, or can it be customized?
A: While 2000L/H is a standard model capacity, we offer customization. We can design and manufacture systems with different capacities based on your specific feed concentration, desired production rate, and product characteristics. -
Q: What kind of after-sales support do you provide?
A: We provide comprehensive support including installation guidance, operator training, technical documentation, and a warranty on the equipment. Our global market presence ensures we can coordinate service and spare parts supply efficiently. -
Q: What is the advantage of double jacket heating over a single coil or jacket?
A: Double jacket heating provides a larger, more uniform heat transfer area. This results in gentler and more consistent heating of the product slurry, which is critical for obtaining a uniform crystal size and minimizing the risk of scaling on the heat transfer surfaces. -
Q: How is the final crystal product separated from the mother liquor?
A: The crystallizer is typically integrated with a solid-liquid separation unit such as a centrifuge or a filter. The system design ensures a steady slurry output that can be fed directly into these downstream separation devices. -
Q: Are your manufacturing facilities certified?
A: Our operations adhere to stringent quality standards. We implement robust quality management systems to ensure product reliability and performance, aligning with international industrial best practices.
