Help CenterProduction Line for CIPP Felt Liners Compliant With ASTM F1216 Standards
Product Spotlights
Related Products
-
Automated CIPP Felt Liner Production System With Integrated Quality InspectionNegotiableMOQ: 1 Piece -
CIPP Felt Liner Production Line for Trenchless Sewer RehabilitationNegotiableMOQ: 1 Piece
-
Customizable CIPP Felt Production Line for High-Temperature Curing ResinsNegotiableMOQ: 1 Piece
-
UV-CIPP Liner Hose Production MachineUS$ 1000 - 110000MOQ: 1 Set
-
UV-CIPP Glass Fiber Liner Hose Production MachineUS$ 1000 - 110000MOQ: 1 Set
As a leading manufacturer with over a decade of expertise in pipeline rehabilitation machinery, Qingdao Yongke Machinery Co., Ltd. proudly presents our advanced Production Line for CIPP Felt Liners. Engineered specifically to meet the stringent requirements of ASTM F1216 standards, this integrated system is designed for manufacturers seeking reliable, efficient, and consistent output of high-quality cured-in-place pipe (CIPP) liners. Operating from our expansive 10,000-30,000 square meter facility in Qingdao, China, we combine robust engineering with precision control to deliver a production solution that enhances your manufacturing capability and product reliability.
This production line represents a significant investment in the future of pipeline rehabilitation technology. It addresses the critical need for standardized, high-performance liner production, enabling manufacturers to supply the growing global infrastructure maintenance market with confidence. Our commitment is reflected in our integrated management systems, certified to ISO9001, ISO14000, and OHSAS18001, ensuring that every unit is built with quality, environmental responsibility, and occupational safety in mind.
Core Product Features & Technical Advantages:
- ASTM F1216 Compliance Engineered: The entire production process is calibrated to produce felt liners that consistently meet the material, dimensional, and performance criteria outlined in ASTM F1216, a critical standard for trenchless pipeline rehabilitation.
- Integrated Multi-Stage Process: From felt roll feeding and precision guiding to resin impregnation, controlled curing, and final cutting/winding, the line automates the complete workflow, minimizing manual handling and variability.
- Precision Impregnation System: Features a closed, metered resin application system ensuring uniform saturation of the felt substrate, which is crucial for the liner's final structural integrity and chemical resistance.
- Programmable Curing Oven: Equipped with multi-zone, temperature-controlled curing tunnels that allow for precise profile management, ensuring complete resin polymerization and optimal physical properties of the finished liner.
- Advanced Control & Monitoring: A centralized PLC with a user-friendly Human-Machine Interface (HMI) provides real-time monitoring of speed, temperature, tension, and resin ratios, enabling repeatable quality and quick troubleshooting.
- Customizable Configuration: The line can be tailored to your specific output requirements, liner dimensions (diameter, wall thickness), and preferred resin systems, offering flexibility for various market demands.
Key Technical Specifications Overview:
| Parameter Category | Typical Specification / Description |
| Production Capacity | Configurable, typically ranging from 500 to 3000+ meters of liner per shift, depending on liner type and thickness. |
| Liner Diameter Range | Wide range capability, commonly from 100 mm (4") to 1200 mm (48") ID, with customization available. |
| Control System | PLC-based (brands like Siemens or Mitsubishi optional) with color touchscreen HMI for process control and data logging. |
| Power Requirements | Designed per customer's local electrical standards (e.g., 380V/50Hz or 480V/60Hz). |
| Key Process Modules | Unwinder, Tension Control, Impregnation Unit, Curing Oven(s), Cooling Section, Cutting System, Winder/Take-up. |
Benefits for Your Manufacturing Operation:
- Assured Product Quality: Automated, controlled processes drastically reduce human error, yielding liners with consistent thickness, resin content, and mechanical properties batch after batch.
- Enhanced Production Efficiency: Streamlines the liner manufacturing process, significantly increasing output per labor hour and reducing production cycle times compared to semi-automatic methods.
- Material & Cost Optimization: Precise resin metering and controlled curing minimize material waste, while consistent quality reduces rejection rates, improving overall profitability.
- Market Competitiveness: The ability to reliably produce ASTM F1216-compliant liners is a powerful credential, allowing you to bid on and secure contracts from municipalities and contractors who mandate this standard.
- Operational Scalability: The modular design allows for future expansion or adaptation to new liner materials and technologies as market needs evolve.
Trust in a partner with a proven global track record. Qingdao Yongke Machinery serves a diverse clientele across North America, South America, Europe, Asia, Africa, and Oceania, with an annual export value between US$1 Million and US$1.5 Million. Our dedicated team of 51-100 professionals provides comprehensive support, including detailed factory acceptance tests, professional installation supervision, on-site commissioning, and thorough operator training. Shipping globally from the Port of Qingdao, we ensure a smooth procurement and delivery process. Investing in this production line is not just a purchase of equipment; it's a partnership for building a more capable and competitive manufacturing business in the essential field of pipeline rehabilitation.
Frequently Asked Questions (FAQ)
1. What exactly does "compliant with ASTM F1216" mean for this production line?
It means the machinery is engineered and calibrated to control all critical production variables (resin impregnation uniformity, curing temperature/time profiles, tension control) necessary to manufacture CIPP felt liners that will meet the material and performance specifications required by the ASTM F1216 standard. The line provides the controlled environment needed for compliance.
2. Can this line handle different types of resins, like epoxy, polyester, or vinyl ester?
Yes, the impregnation system and curing oven parameters are adjustable. The line can be configured to work with various thermosetting resin systems commonly used in CIPP liner manufacturing. Specific compatibility details should be discussed during the project planning phase.
3. What is the typical lead time for delivery and installation?
Lead time depends on the specific configuration and customization level. Generally, for a standard configuration, it ranges from 90 to 150 days after order confirmation. This includes manufacturing, factory testing, and preparation for shipment.
4. Do you provide training for our operators and maintenance staff?
Absolutely. Comprehensive training is a standard part of our service. It includes theoretical instruction on the process and hands-on operational training on the equipment at your site during commissioning. We also provide detailed operation and maintenance manuals.
5. How energy-intensive is the curing oven, and are there efficiency features?
The curing oven is designed with insulated zones and efficient heating elements to minimize energy consumption. The PLC control allows for precise temperature profiling, preventing energy waste. Specific power consumption figures can be provided based on the final line configuration and production speed.
6. What kind of after-sales support and warranty do you offer?
We offer a standard warranty period for the machinery. Our support includes remote technical assistance via phone or video, a supply of commonly required spare parts, and the availability of service engineers for on-site support if needed. We aim for long-term partnership support.
7. Can the production line be upgraded in the future to produce new liner designs?
The modular design is a key feature for future-proofing. Many components, like the impregnation tank, oven modules, or control software, can be upgraded or modified later to accommodate new materials, larger diameters, or enhanced process requirements.
8. What factory acceptance procedures are in place before shipment?
Prior to shipment, we conduct a full Factory Acceptance Test (FAT) at our facility. Customers are welcome to witness this test, where we run the line with representative materials to verify all functions, speeds, and control sequences meet the agreed specifications.
