Help CenterSTEAM TRAP DN25/1INCH, THERMODYNAMIC, THREADED TYPE CONNECTION NPT, ASME CLASS 600 PN63/100 Preferred Brand: ARMSTRONG
Product Spotlights
Related Products
-
FQ1steam Trap Flanged Ball Float Steam Valve (FT14-Flange) Steam TrapNegotiableMOQ: 1 Piece -
Thermodynamic Disc Trap S31n Automatic Water Drain Steam Traps for Steam SystemNegotiableMOQ: 1 Piece
-
WDV CS41H-16C Free Float Steam Trap, Carbon Steel / Stainless Steel, For Chemical Processing, Nuclear Power, Food & Pharmaceutical ApplicationsNegotiableMOQ: 1 Set
-
OEM Inverted Bucket Steam Trap IB Series | High Efficiency Mechanical Steam Trap for Boiler Steam Line | Cast Steel Flanged Steam Trap ManufacturerNegotiableMOQ: 1 Piece
-
Wdv FT14 Lever Float Steam Trap | High Efficiency Ball Float Steam Trap for Heat Exchanger Boiler and Steam Heating SystemsNegotiableMOQ: 1 Piece
Disc Trap
When starting the device,firstly,the air and condensed water will flow across steam trap under rather low pressure,and lift valve plate through the entrance hole,and then discharge from the exit hole.After the pressure and temperature rise,the inner pressure will also rise,and cause increased amount of condensed water and increased flow rate,at the moment, the static pressure of valve plate declines which causes the drop of valve plate,and then,the steam flows from all directions via the exit hole into the gap between the valve plate and the valve cover.After steam enters the pressure chamber,it shuts down the valve by pressing valve plate onto the sealing ring.When the steam temperature inside the pressure chamber begins descending and the steam begins to congeal,the pressure declines in the pressure chamber,and the inlet pressure lifets the valve plate,and then the steam trap opens and discharge water.
Merits
1.Simple structure,easy installation and maintenance and water hammer resistant.
2.Water hammer resistant and on effect from abrupt change of pressure.
3.Adoptable for overheat steam system.
4.Adoptable for high-pressure and high-temperature steam pipes.
