Help CenterComplete Turnkey System for Manufacturing UV-Cured In-Situ Pipe Lining Hoses
Product Spotlights
Related Products
-
Compact UV CIPP Hose Manufacturing Line for Municipal Pipe Repair ContractorsNegotiableMOQ: 1 Set -
Customizable Glass Fiber Reinforced UV CIPP Hose Production SystemNegotiableMOQ: 1 Set
-
Industrial UV CIPP Liner Production Line With Integrated Winding & CuringNegotiableMOQ: 1 Set
-
Robust Production Line for UV-Cured Glass Fiber Liner Hoses With Mill Test ReportNegotiableMOQ: 1 Set
-
CIPP Glass Fiber Liner Machine Compliant With Industry StandardsNegotiableMOQ: 1 Set
As a leading manufacturer with over a decade of expertise in industrial machinery, Qingdao Yongke Machinery Co., Ltd. is proud to introduce our Complete Turnkey System for Manufacturing UV-Cured In-Situ Pipe Lining Hoses. Engineered within our expansive 10,000-30,000 square meter facility, this integrated solution is designed to empower businesses to produce high-quality, durable pipe rehabilitation liners efficiently and reliably. We understand the critical need for robust infrastructure solutions, and our system delivers precisely that by transforming raw materials into finished, UV-cured hoses ready for trenchless pipe repair projects worldwide. This turnkey approach eliminates sourcing complexities, ensuring a seamless path from installation to production for our clients across North America, Europe, Asia, and beyond.
The core value of our system lies in its integration and automation. It consolidates the entire manufacturing process—from resin saturation to final curing—into one coherent, PLC-controlled line. This not only maximizes production consistency and output but also minimizes manual intervention, reducing labor costs and potential human error. For municipalities, contractors, and specialized manufacturers, this means gaining the capability to produce CIPP (Cured-In-Place-Pipe) liners on-demand, controlling quality at the source, and securing a competitive edge in the growing pipeline rehabilitation market.
Detailed System Features & Technical Advantages:
- End-to-End Process Integration: Our turnkey system encompasses every critical stage: material feeding and alignment, precise resin impregnation for uniform saturation, controlled hose winding or braiding for structural integrity, and a high-efficiency UV curing chamber. This holistic design ensures a continuous, uninterrupted production flow.
- Advanced UV Curing Technology: The heart of the system features a customizable UV curing oven with optimized lamp arrays and reflective surfaces. This ensures rapid and complete photopolymerization of the resin, resulting in liners with superior mechanical strength, chemical resistance, and dimensional stability compared to traditional thermal-cured methods.
- Precision Control & Monitoring: A centralized Programmable Logic Controller (PLC) with a user-friendly Human-Machine Interface (HMI) allows operators to monitor and adjust all parameters—such as line speed, resin temperature, UV intensity, and curing time—with precision, guaranteeing repeatable quality across every meter of hose produced.
- Flexible & Scalable Design: The system is engineered to accommodate a range of liner hose diameters and wall thicknesses. Its modular construction allows for future upgrades or capacity expansion, protecting your investment as your business grows.
- Built for Durability & Safety: Constructed with high-grade industrial components, the system is designed for 24/7 operation in demanding environments. Safety features, including emergency stops, ventilation systems, and protective guarding, are integrated throughout, aligning with modern industrial safety protocols.
Technical Specifications Overview:
| Parameter | Specification / Capability |
| Typical Hose Diameter Range | 100mm to 1200mm (customizable) |
| Production Line Speed | Adjustable, typically 0.5 - 3 meters per minute |
| UV Curing Source | Medium-Pressure Mercury Lamps (LED options available) |
| Control System | Industrial PLC with Color Touchscreen HMI |
| Power Supply | Standard 380V, 3Phase, 50Hz (configurable) |
| System Footprint (LxW) | Approx. 25m x 5m (varies with configuration) |
Tangible Benefits for Your Business:
- Reduced Operational Complexity: A single-source solution for your entire manufacturing process, simplifying procurement, installation, training, and maintenance.
- Consistent, High-Quality Output: Automated controls ensure every hose meets stringent specifications for thickness, resin content, and cure level, leading to reliable field performance.
- Increased Production Efficiency: Continuous operation and fast UV curing cycles enable higher output volumes, allowing you to meet larger project deadlines and scale operations.
- Lower Total Cost of Ownership: Energy-efficient UV curing, reduced labor requirements, and minimized material waste contribute to a favorable long-term operational cost profile.
- Market Responsiveness: Produce liners as needed, reducing inventory costs of finished goods and allowing for quick adaptation to specific project requirements (diameter, length, resin type).
Backed by our commitment to quality management (ISO9001), environmental responsibility (ISO14000), and occupational health and safety (OHSAS18001), this turnkey system is a product of rigorous R&D and proven manufacturing practices. With an annual export value reflecting our global reach and a dedicated team of 51-100 professionals, we stand behind every system we ship from the port of Qingdao. We invite you to partner with us to establish or upgrade your pipe rehabilitation hose production capability. Contact Qingdao Yongke Machinery today to discuss your specific requirements and discover how our integrated manufacturing solution can become the reliable foundation of your business growth.
Frequently Asked Questions (FAQ):
-
Q: What level of training and support is provided with the turnkey system?
A: We provide comprehensive on-site installation supervision, commissioning, and detailed operator training. Additionally, we offer extensive technical manuals, remote support, and a supply of critical spare parts to ensure smooth long-term operation. -
Q: Can the system produce hoses for both gravity and pressure pipelines?
A: Yes, absolutely. By adjusting the manufacturing parameters such as resin type, fiber reinforcement, and wall thickness during production, the system can be configured to create hoses suitable for various applications, including sanitary sewers, pressure mains, and industrial pipelines. -
Q: How does UV curing compare to steam or hot water curing in the final product?
A: UV curing offers distinct advantages, including faster cure times (seconds/minutes vs. hours), lower energy consumption, and more consistent curing regardless of ambient conditions. This often results in liners with improved mechanical properties and longer service life. -
Q: Is the system compatible with different types of resin and felt/fabric materials?
A: The system is designed to be versatile. The impregnation unit can handle various UV-curable resins. The material feeding and winding sections can be adapted for different carrier materials (e.g., non-woven felt, woven fabrics) upon request during the design phase. -
Q: What is the typical lead time from order to delivery and installation?
A: Lead time depends on the specific configuration and customization. For a standard system, it typically ranges from 90 to 120 days. We provide a detailed project schedule upon order confirmation to ensure clear planning on your end. -
Q: Do you offer assistance with factory layout and utility planning for the system?
A: Yes, as part of our turnkey service, we provide detailed foundation drawings, utility connection plans (power, air, exhaust), and factory layout recommendations to facilitate a seamless integration into your existing or new facility. -
Q: How energy-intensive is the UV curing process in this system?
A: Modern UV curing is notably energy-efficient. The lamps only consume significant power during the curing phase, and the instant-on/off capability eliminates the standby energy losses associated with maintaining a hot steam boiler. Overall energy consumption is often lower than thermal curing methods.
