The WVS series are single-stage, dry carbon vane vacuum pumps (Single stage Rotary Vane Vacuum Pump), with direct drive, small size, light weight, quiet operation, and oil-free exhaust. Standard accessories include: * Inlet filter * Outlet filter * Pressure regulating valve * Vacuum gauge All pumps of all specifications are available in stock.

Product description:

1) Technical data of WVS-3

* Exhaust volume: 235/280 Liter/Min, 50/60Hz
* Vacuum degree: - 650 mmHg (Max)
* Motor: 0.4Kw, 220V, 1Ph, 50/60Hz
* Size: L x W x H = 500 x 205 x 255 mm
* Weight: 21 Kg

2) Technical data of WVS-5

* Exhaust volume: 405/480 Liter/Min, 50/60Hz
* Vacuum degree: - 650 mmHg (Max)
* Motor: 0.75Kw, 220V, 3Ph, 50/60Hz
* Size: L x W x H = 560 x 205 x 265 mm
* Weight: 33 Kg

3) Technical data of WVS-6

* Exhaust volume: 575/685 Liter/Min, 50/60Hz
* Vacuum degree: - 650 mmHg (Max)
* Motor: 1.5 Kw, 220V, 3Ph, 50/60Hz
* Size: L x W x H = 650 x 270 x 310 mm
* Weight: 44 Kg

4) Technical data of WVS-8

* Exhaust volume: 935/1115 Liter/Min, 50/60Hz
* Vacuum degree: - 650 mmHg (Max)
* Motor: 1.5Kw, 220V, 3Ph, 50/60Hz
* Size: L x W x H = 720 x 300 x 360 mm
* Weight: 73 Kg

5) Technical data of WVS-9

* Exhaust volume: 1130/1350 Liter/Min, 50/60Hz
* Vacuum degree: - 650 mmHg (Max)
* Motor: 2.2Kw, 220V, 3Ph, 50/60Hz
* Size: L x W x H = 764 x 354 x 375 mm
* Weight: 97 Kg


Features:

* Single-stage carbon vane dry vacuum pump
* Air-cooled, no water cooling required
* Small size, light weight, easy to install
* Comes with a small inlet filter
* TEFC motor
