Workstation Water Treatment Analysis System

1. Hardware Parameter Indicators

Potentiostat potential control range: ±10V

Current control range: ±2.0A

Potential control accuracy: 0.1%×full-scale reading ±1mV

Current control accuracy: 0.1%×full-scale reading

Potential resolution: 10uV(>100Hz), 2uV(

Current resolution: 10pA

Potential rise time:

Auxiliary data acquisition: 24-bit @100Hz; 20bit@1KHz

Reference electrode input impedance: 1012 ohms || 50pF

Current range: 2A～200nA, a total of 8 ranges

Cell voltage: 21V

CV and LSV scanning speed: 0.01mV～10000V/s

CA and CC pulse width: 0.0001～65000s

Potential increment during potential scanning: 0.1mV@1V/mS

SWV frequency: 0.001～100KHz

DPV and NPV pulse width: 0.0001～1000s

AD data acquisition: 16-bit @1MHz, 24-bit @100Hz

Minimum potential increment of CV: 0.075mV

Potential and current measurement low-pass filter

Current and potential range: Automatic setting

Interface communication mode: USB2.0

2. Electrochemical Impedance Measurement Indicators

Signal Generator

Frequency response: 10uHz~115kHz

AC signal amplitude: 0mV~2500mV

DC bias voltage: -10~+10V

DDS output impedance: 50 ohms

Waveform: Sine wave, triangular wave, square wave

Sine wave distortion:

Scanning method: Logarithmic/linear, increasing/decreasing

Load capacitance: 1nF; Load inductance: 10uH

Signal Analyzer

Integration time: Minimum value: 10mS or the longest time of one cycle

               Value: 106 cycles or 105 S

Measurement time delay: 0~105 seconds

DC offset compensation

Automatic potential compensation range: -10V~+10V

Current compensation range: -1A~+1A

Bandwidth adjustment (Bandwidth): Automatic or manual setting, with a total of 8 levels adjustable



CorrTestTM Main functions of measurement and control software

Open circuit potential-time curve (OCPT)

Potentiostatic method (Chronoamperometry, CA)

Galvanostatic method (Chronopotentiometry, CP)

Multi-potential step (VSTEP)

Multi-current step (ISTEP)

Potentiodynamic scanning (Polarization curve)

Linear polarization (LPR)

Passivation reverse scan curve (Reverse scan according to breakdown current)

Galvanodynamic scanning

Arbitrary potentiostatic square wave

Arbitrary galvanostatic square wave

Galvanostat

Cyclic Voltammetry (CV)

Staircase Voltammetry (SCV)

Differential Pulse Voltammetry (DPV)

Normal Pulse Voltammetry (NPV)

Square Wave Voltammetry (SWV)

AC Voltammetry (ACV)

Stripping Voltammetry

Normal Differential Pulse Voltammetry (DNPV)
Differential Pulse Amperometry (DPA)
Double Differential Pulse Amperometry (DDPA)

Electrochemical Impedance

Electrochemical Noise Measurement

Galvanic Corrosion Measurement

Hydrogen Permeation Monitoring

Corrosion Rate Calculation



Application Fields

1) Study of electrochemical mechanisms; Qualitative and quantitative analysis of substances;

2) Routine electrochemical tests, including electrosynthesis, electroplating, and battery performance evaluation;

3) Research on the mechanism and preparation of functional materials and energy materials;

4) Rapid evaluation of corrosion inhibitors, water quality stabilizers, coatings, and cathode protection efficiency, as well as hydrogen permeation testing, etc.;

5) Corrosion electrochemical tests of metal materials in conductive media (including environments such as water/concrete).



System Configuration

Each workstation includes:

1) One instrument host;

2) One platinum electrode, one reference electrode, one working electrode, and one set of special electrolytic cell;

3) One simulated electrolytic cell;

4) One USB data cable;

5) One special cable for noise measurement;

6) One CD of CorrTestTM testing and analysis software.
