1. Standard core dimensions
Inner diameter d: 105 mm
Outer diameter D: 174.625 mm
Inner ring width B: 81 mm
Outer ring width C: 45.3 mm
Weight: GR ≈ 5.71 kg; EX ≈ 5.55 kg
Cage: M = High-strength brass solid cage
Structure: The inner and outer rings, rollers, and cage are all split in half, allowing direct assembly on the shaft without dismantling it
II. Model Interpretation
01: Medium-sized heavy-duty split bearing series
E: Enhanced type, with more rollers, and a load capacity approximately 30% higher than the regular 01B
B: Standard width series
105: Nominal inner diameter 105mm
M: Brass solid cage
GR: Fixed end, bearing radial + bidirectional axial force
EX: Floating end, radial load only, allowing axial thermal expansion and sliding
III. Core Load and Limit Parameters
Basic dynamic load Cr: 320 kN
Basic static load Cor: 421 kN
Limit speed: 2340 r/min
Operating temperature: -20℃ to 100℃ (short-term 120℃)
IV. Performance Advantages
Quick-change without dismantling the shaft: No need to dismantle the main shaft/coupling, allowing for quick replacement even in confined spaces, significantly reducing downtime
Heavy-load high rigidity: suitable for medium and low-speed shaft systems with high power and heavy impact loads, with superior rigidity compared to ordinary bearings of the same size
Self-aligning and fault-tolerant: It allows ±0.5° misalignment statically, reduces the requirement for installation coaxiality, and adapts to scenarios with base deformation
Sealed, dustproof, and waterproof: Equipped with a labyrinth seal and a contact composite seal as standard, suitable for harsh working conditions such as dust and moisture
Easy maintenance: Equipped with P01 series split bearing housings, it facilitates convenient grease filling and ensures high maintenance efficiency
V. Typical Applications
Mining machinery: large scraper conveyor, feeder, crusher main gear shaft
Metallurgical equipment: hot rolling/cold rolling roller table, drive long shaft, tension roller, coiler
Conveying machinery: heavy-duty belt conveyor roller shaft, bucket elevator, chain conveyor
General machinery: large reducers, fans, pumps, long-span transmission shafts
VI. Installation and pairing
Standard configuration: **01EB105MGR (fixed) + 01EB105MEX (floating)** used in combination
Compatible with: Cooper original P01 split bearing housing, no need to modify the shaft diameter or the base
Lubrication: For medium speed and light load, choose lithium-based grease; for low speed and heavy load, choose extreme pressure lithium-based grease
