1. Basic dimensions (metric system)
Inner diameter d: 90 mm
Outer diameter D: 152.4 mm
Inner ring width C: 70.7 mm
Width B: 38.9 mm
Weight: ≈4.0 kg
II. Core Performance (GR Positioning Type)
Basic dynamic load Cr: 234 kN
Basic static load Cor: 299 kN
Limit speed: 3,000 r/min (grease lubrication)
Axial capability: bidirectional axial positioning (GR)
Cage: Solid brass cage (M), heavy-duty, heat-resistant, and resistant to deformation
III. Structural Features
Fully disassembly: The inner and outer rings, rollers, and cages can all be split in half, allowing for replacement without dismantling the shaft or equipment, significantly reducing downtime.
01E Enhanced: Larger rollers and stronger load-bearing capacity, with a dynamic load increase of approximately 29% compared to the standard 01 series, and a longer lifespan.
Bidirectional positioning (GR): It can simultaneously withstand radial and bidirectional axial loads, making it suitable for heavy-duty rotating parts that require axial fixation.
Static alignment compensation: compatible with SKF Cooper split bearing housings, allowing a certain degree of shaft-housing alignment deviation.
IV. Typical Applications
Conveyor, large fan, pump, crusher, mixer
Heavy equipment for mining, metallurgy, cement, paper-making, etc
Medium and low-speed heavy-load scenarios with narrow space and difficulty in dismantling shafts
V. Model Description
01: Medium series
E: Enhanced
B: Cylindrical roller, bidirectional positioning
90: Inner diameter 90 mm
M: Brass cage
GR: Bi-directional axial positioning (fixed end)
