1. Basic dimensions (metric system)
Inner diameter d: 65 mm
Outer diameter D: 114.3 mm
Inner ring width C: 55.7 mm
Width B: 55.7 mm
Weight: ≈1.74 kg
II. Core Performance (GR Positioning Type)
Basic dynamic load Cr: 135 kN
Basic static load Cor: 157 kN
Limit speed: 3,940 r/min (grease lubrication)
Axial capability: bidirectional axial positioning (GR), capable of withstanding bidirectional axial loads
Cage: Solid brass cage (M), heavy-duty, heat-resistant, deformation-resistant, long-lasting
III. Structural Features
Fully split design: The inner and outer rings, rollers, and cages can all be split in half, allowing for installation and replacement without dismantling the shaft or equipment, significantly reducing downtime.
01E Enhanced Series: Optimized roller and cage design, with significantly improved load capacity and service life compared to the standard 01 Series.
Dual-directional positioning (GR): Capable of simultaneously withstanding radial and dual-directional axial loads, suitable for heavy-duty rotating parts requiring axial fixation.
Static alignment compensation: It is compatible with SKF Cooper split bearing housings, allowing a certain static alignment deviation between the shaft and the bearing housing.
IV. Typical Applications
Conveyor, large fan, pump, crusher, mixer
Heavy equipment for mining, metallurgy, cement, paper-making, etc
In scenarios involving medium and low-speed heavy loads, where space is limited and shaft disassembly is challenging
V. Model Description
01: Medium-sized series
E: Enhanced
B: Cylindrical roller, dual-direction positioning
65: Inner diameter 65 mm
M: Brass cage
GR: Bi-directional axial positioning (fixed end)
