1. Basic dimensions (metric system)
Inner diameter d: 85 mm
Outer diameter D: 165 mm
Inner ring width C: 78 mm
Outer ring width C₁: 48 mm
Weight: 4.33 kg
II. Core Performance (GR Positioning Type)
Basic dynamic load Cr: 228 kN
Basic static load Cor: 325 kN
Basic axial load Ca: 18.2 kN
Limit speed: 2,250 r/min (grease lubrication)
Axial capability: Bidirectional axial positioning (GR), capable of withstanding bidirectional axial loads
Cage: Solid brass cage (M), heavy-duty, heat-resistant, deformation-resistant, long-lasting
III. Structural Features
Fully dismountable design: The inner and outer rings, rollers, and cages can all be disassembled in half, allowing for installation and replacement without dismantling the shaft or equipment, significantly reducing downtime.
01E Enhanced Series: With optimized roller and cage designs, the load capacity and lifespan have been significantly improved compared to the standard 01 Series.
Dual-directional positioning (GR): It can simultaneously withstand radial and bidirectional axial loads, making it suitable for heavy-duty rotating parts that require axial fixation.
Static alignment compensation: It is compatible with SKF Cooper split bearing housings, allowing a certain degree of static alignment deviation between the shaft and the bearing housing.
IV. Typical Applications
Conveyor, large fan, pump, crusher, mixer
Heavy equipment for mining, metallurgy, cement, paper-making, etc
Low and medium speed heavy-load scenarios with narrow space and difficulty in dismantling axles
V. Model Description
01: Medium-sized series
E: Enhanced
B: Cylindrical roller, dual-direction positioning
85: Inner diameter 85 mm
M: Brass cage
GR: Bidirectional axial positioning (fixed end)
