G215HAN01.3 Parameter Overview
AUO’s 21.5-inch FHD industrial-grade LCD module features an AHVA (IPS-like) panel, offering stable performance across all viewing angles. It is specifically designed for industrial control, medical, and self-service terminal applications.
?? Key specifications.
Dimensions and Resolution: 21.5 inches, 1920×1080 (FHD), pixel pitch of 247.95μm.
Display characteristics: Brightness of 250 cd/m2 (typical), contrast ratio of 1000:1, response time of 22 ms (typical), color gamut of 72% NTSC.
Viewing Angle and Surface: Full-angle view of 89°/89°/89° /89°, anti-glare (AG) + 3H hard coating.
Interface and Power Supply: Dual-channel LVDS (2 channels, 8-bit), 30-pin JAE connector; operating voltage: 5V (typical); total system power consumption: approximately 11.1W.
Temperature and humidity range: Operates from 0 to 60°C, stores from -20 to 60°C; weight: approximately 1.74 kg.
?? Mechanics and sequencing.
Dimensions: 497.6 × 292.2 × 10.5 mm (length × width × thickness)
Effective area: 476.064 × 267.786 mm
Clock frequency: 53.7 to 71.2 MHz, refresh rate: 60 Hz (typical).
?? Additional explanation.
This model features inverted terminals (FI-X30 series) and is designed for compact installation in industrial equipment.
The backlight is WLED, with a lifespan of ≥50,000 hours, making it suitable for long-term continuous operation.
