P170ETN01.1 is a 17.0-inch LCD module product launched by AU Optronics. The following are its detailed parameters:
1.?Basic Information: The screen type is a-Si TFT-LCD; resolution is 1280 (RGB) × 1024 (SXGA), pixel layout is RGB vertical stripe, aspect ratio is 5∶4, dot pitch is 0.088×0.264mm, and pixel pitch is 0.264×0.264mm.
2.?Operating Environment: Operating temperature is 0~50°C, storage temperature is -20~60°C, and vibration resistance is 1.5G (14.7m/s2).
3.?Structural Details: The display area is 337.92×270.336mm, the visible size is 341.72×274.14mm, the overall dimension is 358.5×296.5×10.8mm, the net weight of the product is 1.27Kgs, the surface treatment is matte with Hard coating (3H), the appearance shape is a flat rectangle with landscape mode, and the mounting holes are side mounting holes (4-M3) on the left and right bezels.
4.?Optical Parameters: The display brightness is 250cd/m2, the transmission contrast ratio is 1000∶1, the viewing angle is 85/85/80/80 (Typ.) (CR≥10) (L/R/U/D), the response time is 3.8/1.2 (Typ.) (Tr/Td) ms, the display color is 16.7M, and the color saturation is 72% (NTSC).
5.?Backlight Parameters: It adopts 9S4P WLED light-emitting edge-lit light source (bottom), the service life of the light source is 30K hours, and it does not include a backlight driver.
6.?Electrical Parameters: It adopts LVDS (2ch, 8-bit) signal interface with a total of 30 pins, connected by terminals, the driving voltage is 5.0V (Typ.), and the typical vertical refresh rate is 75Hz
