Help CenterSupply M185XTN01.2 AUO 18.5-inch LCD Screen, Kaixian Technology Inquiry Machine, Advertising Machine, Cash Withdrawal All-in-one Unit
Product Spotlights
Related Products
-
Supply M190ETN01.0 AUO 19-inch LCD Screen, Kaixian Technology Inquiry Machine, Advertising Machine, Cash Withdrawal All-in-one UnitUS$ 69MOQ: 270 Blades -
Supply of M170ETN01.1 AUO, AU Optronics 17-inch Original Assembly/refurbished Display Panel, KaiXian Technology 21.5, 27-inch, 32-inchUS$ 62MOQ: 270 Blades
-
Supply P170ETN01.0 AUO 19-inch Original Second-hand Industrial Display, Medical, Military, Fire Protection and Security LG.US$ 61MOQ: 270 Blades
-
Supply T215HVN01.1 AUO 21.5-inch LCD Screen, Kaixian Technology Inquiry Machine, Advertising Machine, Cash Withdrawal All-in-one UnitUS$ 29MOQ: 440 Blades
-
G070VW01 V0 AU Optra 7-inch Industrial Display, KY Display AUOUS$ 42MOQ: 10 Blades
M185XTN01.2 is an 18.5-inch LCD module product launched by AU Optronics. Its detailed parameters are as follows:
1.?Panel Type: a-Si TFT-LCD, LCM
2.?Resolution: 1366 (RGB) × 768, WXGA
3.?Pixel Format: RGB vertical stripe
4.?Dot Pitch: 0.100×0.300 mm (H×V)
5.?Pixel Pitch: 0.300×0.300 mm (H×V)
6.?Display Area: 409.8×230.4 mm (H×V)
7.?External Dimensions: 430.4×254.6 mm (H×V)
8.?External Thickness: 7.8/10.3mm (Typ./Max.)
9.?Surface Treatment: Matte, Hard coating (3H)
10.?Brightness: 250 cd/m2 (Typ.)
11.?Contrast Ratio: 1000:1 (Typ.) (Transmissive)
12.?Viewing Angle: 85/85/80/80 (Typ.) (CR≥10) (Left/Right/Up/Down)
13.?Display Mode: TN, normally white display, transmissive
14.?Response Time: 3.6/1.4 (Typ.) (Tr/Td) ms
15.?Display Color: 16.7M (6-bit + Hi-FRC)
16.?Color Gamut: 72% NTSC (CIE1931)
17.?Backlight Type: WLED, edge-lit (right side)
18.?Backlight Life: 30K (Min.) Hours
19.?Signal Interface: LVDS (1 ch, 8-bit), 30-pin terminal
20.?Input Voltage: 5.0V (Typ.)
21.?Operating Temperature: 0~50°C
22.?Storage Temperature: -20~60°C
23.?Operating Humidity: 5-95% (RH)
24.?Storage Humidity: 5-95% (RH)
25.?Panel Weight: 1.29Kgs (Typ.)
Send Inquiry to This Supplier
