12 mesh 304 woven stainless steel wire mesh / ss screening mesh / 1400 micron stainless steel mesh
stainless steel wire mesh weave types:
stainless steel wire mesh
Material: AISI 201, 202, 302, 304, 316, 316L, 410
Wire dia: 0.0203-0.89mm
Mesh: 0.0203-3.35mm
Features: Acid resistant, alkali resistant, heat resistant, corrosion resistant.
excellent corrosion resistance:the excellent corrosion resistance of stainless steel wire exceeds polyester fiber.
Non-electronic:to avoid affects of nonelectrostatic for printing and ensure the safety of printing.
special features of steel wire mesh suitable for heat-melting ink.
to avoid the affects of any solvents to wire mesh and to ensure the satety of printing
Uses: Used in mine, petroleum, chemical, food, medicine, machine making, etc.
Weaving Patterns:
ss 304 Plain Weave wire mesh
ss 316L Twill Weave wire mesh
Dutch Plain Weave wire mesh
Dutch Twill Weave wire mesh
Part of detailed specification:
|
mesh /inch |
wire diameter /mm |
aperture /mm |
mesh /inch |
wire diameter /mm |
aperture /mm |
| 2mesh | 1.8 | 10.9 | 60mesh | 0.15 | 0.273 |
| 3mesh | 1.6 | 6.866 | 70mesh | 0.14 | 0.223 |
| 4mesh | 1.2 | 5.15 | 80mesh | 0.12 | 0.198 |
| 5mesh | 0.91 | 4.17 | 90mesh | 0.11 | 0.172 |
| 6mesh | 0.81 | 3.433 | 100mesh | 0.1 | 0.154 |
| 8mesh | 0.6 | 2.575 | 120mesh | 0.08 | 0.132 |
| 10mesh | 0.55 | 1.99 | 140mesh | 0.07 | 0.111 |
| 12mesh | 0.5 | 1.616 | 150mesh | 0.065 | 0.104 |
| 14mesh | 0.45 | 1.362 | 160mesh | 0.065 | 0.094 |
| 16mesh | 0.4 | 1.188 | 180mesh | 0.053 | 0.088 |
| 18mesh | 0.35 | 1.06 | 200mesh | 0.053 | 0.074 |
| 20mesh | 0.3 | 0.97 | 250mesh | 0.04 | 0.061 |
| 26mesh | 0.28 | 0.696 | 300mesh | 0.035 | 0.049 |
| 30mesh | 0.25 | 0.596 | 325mesh | 0.03 | 0.048 |
| 40mesh | 0.21 | 0.425 | 350mesh | 0.03 | 0.042 |
| 50mesh | 0.19 | 0.318 | 400mesh | 0.025 | 0.0385 |
