High Grade Dutch Weave Stainless Woven Steel Wire Micron Mesh Cloth Netting
Square wire mesh, also known as square woven wire mesh, is a kind of mesh product made by interweaving high-quality metal wires in a right-angle (square) pattern. The wires are carefully woven to form uniform square openings, with the wire diameter and mesh size customizable according to specific application needs. It is available in a variety of metal materials, including low carbon steel, stainless steel, aluminum, copper, and galvanized steel, each bringing unique performance to adapt to different working environments.
The manufacturing process of square wire mesh emphasizes precision and consistency, ensuring that each mesh opening maintains the same size and shape for stable performance. It can be further processed into various forms such as rolls, sheets, or customized shapes through cutting, bending, and edge treatment, making it highly flexible in practical applications.
One of the core advantages of square wire mesh is its excellent structural stability and load-bearing capacity. The interlocking square weave structure distributes pressure evenly across the entire mesh surface, enabling it to withstand moderate mechanical impact and weight without easy deformation or damage. Compared with other mesh types, it has better dimensional stability, ensuring long-term use without significant changes in mesh size.
Another notable advantage is its versatility and cost-effectiveness. The wide range of material options allows it to adapt to different environments, such as corrosion resistance in humid or chemical environments when using stainless steel, and lightweight performance when using aluminum. Additionally, the mature manufacturing process makes it easy to produce on a large scale, resulting in relatively low production costs while maintaining high quality, providing cost-effective solutions for various industries.
Specification
Specification
Mesh |
Wire Diameter(mm) |
Opening(mm) |
3 |
1.60 |
6.87 |
4 |
1.20 |
5.15 |
5 |
0.95 |
4.13 |
6 |
0.80 |
3.43 |
8 |
0.70 |
2.34 |
10 |
0.60 |
1.94 |
12 |
0.55 |
1.56 |
14 |
0.41 |
1.40 |
16 |
0.35 |
1.24 |
18 |
0.30 |
1.11 |
20 |
0.27 |
1.00 |
22 |
0.25 |
0.90 |
24 |
0.23 |
0.83 |
26 |
0.20 |
0.78 |
28 |
0.18 |
0.73 |
30 |
0.15 |
0.70 |
35 |
0.14 |
0.59 |
40 |
0.14 |
0.50 |
50 |
0.12 |
0.39 |
60 |
0.12 |
0.30 |
