5.5m 6m 5m 4m AISI304 316 Stainless Steel 1.2mm 5X5 Mesh Wire Mesh Screen for Paper Mill
Ultra width stainless steel wire mesh is a kind of weave stainless steel wire mesh. The mesh count can be 1-250 mesh. The weave type have plain and twill weaving. Because of its big width of the mesh, it is usually used in the field of high-precision filtration.
Application: wind tunnel test, for large size reactor screen,
Material: 304, 304L, 316, 316L, 904L, 2205, 2507, 430 etc.
Mesh: 2-12m
Roll size: can be custom as your requirement.
Stainless Steel Wire Mesh
Stainless steel wire mesh is a kind of mesh made of stainless steel.
Material: Stainless steel wire 304,304L,316,316L and so on
Weaving: Plain weave, twill weave, dutch weave
Mesh: 2 mesh-500 mesh
Usage:
1. For acid, alkali conditions for screening and filtering, the petroleum industry as mud mesh, chemical fiber industry, as the sieve plating.
2. For mining, petroleum, chemical, food, medicine, machinery manufacturing, and other industries.
3. For acid, alkali conditions sieving and filtering, the mud for the oil industry, chemical fiber industry as screen, electroplating industry for pickling net, the factory can according to user needs to design the production of various types of products.
Specification
| Mesh | Wire Diameter (mm) | Opening (mm) | Mesh | Wire Diameter (mm) | Opening (mm) | |
| 2×2 | 1.60 | 11.10 | 40×40 | 0.25 | 0.38 | |
| 3×3 | 1.37 | 7.09 | 50×50 | 0.20 | 0.31 | |
| 4×4 | 1.60 | 4.75 | 60×60 | 0.18 | 0.23 | |
| 4×4 | 1.19 | 5.16 | 60×60 | 0.18 | 0.25 | |
| 5×5 | 1.00 | 4.04 | 70×70 | 0.12 | 0.24 | |
| 6×6 | 0.89 | 3.35 | 80×80 | 0.14 | 0.15 | |
| 8×8 | 0.71 | 2.46 | 90×90 | 0.12 | 0.16 | |
| 10×10 | 0.64 | 1.91 | 100×100 | 0.10 | 0.15 | |
| 12×12 | 0.58 | 1.52 | 120×120 | 0.09 | 0.12 | |
| 12×12 | 0.50 | 1.60 | 150×150 | 0.063 | 0.11 | |
| 14×14 | 0.23 | 1.22 | 180×180 | 0.053 | 0.09 | |
| 14×14 | 0.50 | 1.30 | 200×200 | 0.053 | 0.07 | |
| 16×16 | 0.45 | 1.13 | 250×250 | 0.04 | 0.063 | |
| 18×18 | 0.43 | 0.98 | 300×300 | 0.04 | 0.044 | |
| 20×20 | 0.40 | 0.87 | 325×325 | 0.035 | 0.043 | |
| 24×24 | 0.35 | 0.70 | 350×350 | 0.03 | 0.042 | |
| 30×30 | 0.30 | 0.54 | 400×400 | 0.028 | 0.036 | |
| 30×30 | 0.23 | 0.62 | 450×450 | 0.028 | 0.028 | |
| 35×35 | 0.28 | 0.45 | 500×500 | 0.025 | 0.026 |
