SS304 SS316 Micron Screen Stainless Steel Wire Mesh Filter
stainless steel wire mesh,with its excellent resistance against acid,alkali,heat and corrosion,find extensive uses in processing of oils,chemicals,food, pharmaceuticals,also sorting and screening of solid ,liquid and gas in mine,metallurgy,airspace,machine making ,etc.we also can provide other specification according to the clients' requrements.Meanwhile ,we accept the business of processing supply meterial.About stainless steel square wire mesh sizes,standard roll width of stainless steel square wire mesh:1m to 48' ,standard roll length of stainless steel square wire mesh :30m to 100'
Stainless Steel Wire Mesh
Stainless steel wire mesh is a kind of mesh made of stainless steel.
Material: Stainless steel wire 304,304L,316,316L and so on
Weaving: Plain weave, twill weave, dutch weave
Mesh: 2 mesh-500 mesh
Usage:
1. For acid, alkali conditions for screening and filtering, the petroleum industry as mud mesh, chemical fiber industry, as the sieve plating.
2. For mining, petroleum, chemical, food, medicine, machinery manufacturing, and other industries.
3. For acid, alkali conditions sieving and filtering, the mud for the oil industry, chemical fiber industry as screen, electroplating industry for pickling net, the factory can according to user needs to design the production of various types of products.
Specification
| Mesh | Wire Diameter (mm) | Opening (mm) | Mesh | Wire Diameter (mm) | Opening (mm) | |
| 2×2 | 1.60 | 11.10 | 40×40 | 0.25 | 0.38 | |
| 3×3 | 1.37 | 7.09 | 50×50 | 0.20 | 0.31 | |
| 4×4 | 1.60 | 4.75 | 60×60 | 0.18 | 0.23 | |
| 4×4 | 1.19 | 5.16 | 60×60 | 0.18 | 0.25 | |
| 5×5 | 1.00 | 4.04 | 70×70 | 0.12 | 0.24 | |
| 6×6 | 0.89 | 3.35 | 80×80 | 0.14 | 0.15 | |
| 8×8 | 0.71 | 2.46 | 90×90 | 0.12 | 0.16 | |
| 10×10 | 0.64 | 1.91 | 100×100 | 0.10 | 0.15 | |
| 12×12 | 0.58 | 1.52 | 120×120 | 0.09 | 0.12 | |
| 12×12 | 0.50 | 1.60 | 150×150 | 0.063 | 0.11 | |
| 14×14 | 0.23 | 1.22 | 180×180 | 0.053 | 0.09 | |
| 14×14 | 0.50 | 1.30 | 200×200 | 0.053 | 0.07 | |
| 16×16 | 0.45 | 1.13 | 250×250 | 0.04 | 0.063 | |
| 18×18 | 0.43 | 0.98 | 300×300 | 0.04 | 0.044 | |
| 20×20 | 0.40 | 0.87 | 325×325 | 0.035 | 0.043 | |
| 24×24 | 0.35 | 0.70 | 350×350 | 0.03 | 0.042 | |
| 30×30 | 0.30 | 0.54 | 400×400 | 0.028 | 0.036 | |
| 30×30 | 0.23 | 0.62 | 450×450 | 0.028 | 0.028 | |
| 35×35 | 0.28 | 0.45 | 500×500 | 0.025 | 0.026 |
