Help CenterIntelligent Vortex Flowmeter
Product Spotlights
2. No mechanical moving parts, thus requiring no maintenance and offering a longer service life.
3. Integrated temperature and pressure compensation ensures accurate and stable readings in steam trading.
Related Products
Measuring medium: Gas, liquid, steam
Connection method: Flange clamp type, flange type, insertion type
Caliber specification: For flange clamp type, the available calibers are 25, 32, 50, 80, 100
For flange connection type, the available calibers are 100, 150, 200
Flow measurement range: The normal measurement flow velocity range is within the Reynolds number of 1.5×104～4×106; 5～50m/s for gas; 0.5～7m/s for liquid.
The normal measurement flow range: See Table 2 for the flow measurement range of liquid and gas; see Table 3 for the steam flow range.
Measurement accuracy: Grade 1.0, Grade 1.5
Temperature of the measured medium: Normal temperature –25℃～100℃, high temperature –25℃～150℃, -25℃～250℃
Output signal: Pulse voltage output signal, high level 8～10V, low level 0.7～1.3V
The pulse duty cycle is about 50%, and the transmission distance is 100m
Pulse current remote transmission signal: 4～20 mA, the transmission distance is 1000m
Instrument operating environment: Temperature: -25℃～+55℃, Humidity: 5～90% RH50℃
Material: Stainless steel, aluminum alloy
Power supply: DC24V or lithium battery 3.6V
Explosion-proof grade: Intrinsically safe type iaIIbT3-T6, protection grade IP65.
