General Electric IS42yPVIBH1B Unsafe vibration monitoring
The IS420PVIBH1B is a GE Mark VIe series PVIB type non-safety vibration monitoring I/O module, adapted for vibration/key phase/speed signal acquisition in turbines and rotating machinery. It features 4-channel vibration + key phase processing, a 24-bit ADC, and redundant IONet communication, making it a core component of Mark VIe rotating machinery condition monitoring.
Core Performance:
Signal Acquisition Capabilities
Channel Configuration: 4 vibration inputs (ICP/IEPE accelerometer) + 1 key phase/speed input, with electrical isolation between channels; a single channel failure does not affect other channels.
Signal Processing: 24-bit ADC, sampling rate up to 128kHz, supports FFT spectrum/time domain analysis, adapted for turbine shaft vibration, bearing vibration, and speed monitoring.
Diagnostics: Channel-level signal integrity monitoring, LED indicators for module/channel status, ControlST remote diagnostics, and rapid fault location.
Power Supply and Communication Characteristics
Power Supply: 24-28VDC redundant input, hot-swappable design, maintenance without interrupting system operation.
Communication: Dual 100M full-duplex Ethernet (IONet redundancy), compatible with Mark VIe TMR/DCS, seamless switching in case of link failure.
Expansion: Supports terminal block expansion, suitable for large-scale vibration signal acquisition scenarios.
Safety and Environmental Characteristics
Certifications: Class 1 Div 2/ATEX explosion-proof, suitable for deployment in hazardous areas.
Environment: Operating temperature -30℃ to 65℃, vibration/shock resistant, adaptable to harsh industrial environments.
Protection: Overvoltage/reverse connection protection, fault isolation, preventing system failure propagation.
Email: xmxblynn@163.com
Phone: +86 18059884797
Key Technical Parameters
Parameter Value
Model IS420PVIBH1B (Mark VIe PVIB Vibration Monitoring I/O Module)
Compatible System GE Mark VIe TMR/DCS Control System
Input Channels 4-channel ICP/IEPE vibration + 1-channel key phase/speed input
Sampling Accuracy 24-bit ADC, maximum sampling rate 128kHz
Communication Interface Dual 100M full-duplex Ethernet (IONet redundancy)
Power Supply Input 24-28VDC redundancy, supports hot-swapping
Operating Temperature -30℃ to 65℃
Installation Method Standard Mark VIe rack mount
Compliance Class 1 Div 2, ATEX, CE/UL
Status Mark VIe in-service spare parts, used for vibration monitoring module replacement
Typical Applications Turbine Vibration Monitoring: Adapted for monitoring shaft vibration and bearing vibration in gas/steam turbines, supports FFT spectrum analysis, used for turbine condition monitoring and fault early warning.
Rotating Machinery Condition Management: Vibration/speed monitoring of fans, pumps, and compressors in petrochemical/power units, adapting to predictive maintenance needs.
Redundant System Deployment: Dual power supply + IONet redundant communication ensures signal link and power supply continuity, improving system availability.
Spare Parts Replacement and Upgrade: Compatible with existing Mark VIe systems for replacing faulty vibration monitoring modules, supporting automatic reconfiguration for convenient maintenance.
