Material Grades
• Carbon structural steel: Q235B, Q235C (suitable for conventional load-bearing scenarios with excellent weldability)
• Low-alloy high-strength structural steel: Q345B, Q345C, Q355B, Q355C (higher strength, suitable for large-span and heavy-load structures)
• Special materials: Q420, Q460 and other high-strength steels (customizable on demand, used in special projects such as super high-rise buildings and heavy industrial workshops)
• Standard compliance: All materials comply with national standards including GB/T 700 Carbon Structural Steel, GB/T 1591 Low-Alloy High-Strength Structural Steel, and GB/T 11263 Hot-Rolled H-Steel and Split T-Steel, and can be produced in accordance with international standards such as ASTM A6/A6M, EN 10025, and JIS G3133.
Core Dimensional Range
• HW Series (Wide Flange H-Steel)
◦ Height (H): 100mm - 1000mm
◦ Flange Width (B): 100mm - 1000mm
◦ Web Thickness (t₁): 6mm - 40mm
◦ Flange Thickness (t₂): 8mm - 50mm
◦ Standard Length (L): 6m - 12m (customizable up to 18m)
• HM Series (Medium Flange H-Steel)
◦ Height (H): 148mm - 900mm
◦ Flange Width (B): 100mm - 800mm
◦ Web Thickness (t₁): 6mm - 36mm
◦ Flange Thickness (t₂): 8mm - 48mm
◦ Standard Length (L): 6m - 12m (customizable up to 18m)
• HN Series (Narrow Flange H-Steel)
◦ Height (H): 100mm - 900mm
◦ Flange Width (B): 50mm - 400mm
◦ Web Thickness (t₁): 5mm - 32mm
◦ Flange Thickness (t₂): 7mm - 40mm
◦ Standard Length (L): 6m - 12m (customizable up to 18m)
