Fully automatic alloy saw blade tooth grinding machineAX900-B2Model Introduction
The fully automatic alloy saw blade tooth grinding machineAX900-B2 model is a mechanical equipment for grinding and reusing alloy circular saw blades. It can grind all tooth profiles included in the rake angle and clearance angle of alloy circular saw blades. A single machine can grind 30 - 50 alloy saw blades in 8 hours a day. It is a commonly used equipment for saw blade users and saw blade manufacturers. PLC control, color touch screen display. The feed system uses a precision waterproof stepping motor. Flat and ladder teeth can be ground at one time, and the same tooth can be ground repeatedly 2 - 3 times. The accuracy can be controlled within 0.03mm. It is easy to operate and learn. There is no need for unlocking and locking buttons, and the system automatically locks according to the operation requirements. On the premise of grinding the saw blade sharp, it can also fully extend the service life of the saw blade. Each blade can be reused 20 - 30 times. It has been well - received by a wide range of users, including Guangzhou Oppein, Zhongshan Ouli Furniture, Dongguan LvDian Furniture, Heshan YouYue Furniture, Wuhan Fanzhou Zhongyue, Jiangxi Ganzhou Hongshan Wood Industry, and Anhui Lu'an Guanzhong Wood Industry.
The power supply of this model is three - phase 380V, 50HZ (another colored wire is the grounding wire). The machine operates under PLC control, with a touch - screen display and hydraulic drive. It uses the Delta brand PLC (DVP60ES200T) and color touch screen (DOP - B07S410) produced by Delta Electronics, which shows better matching stability. The hydraulic system uses a 24V solenoid valve produced by Beijing Shida Company, is equipped with a 380V 0.75KW special hydraulic motor and a 20L special variable hydraulic pump, and is configured with a hydraulic stability system to ensure balanced hydraulic operation. The motor uses Tianyang Motor, a high - quality product in Guangdong Province. Professional matching makes the equipment more stable and durable.
