H Single Stage Piston Vacuum Pump

H Single Stage Piston Vacuum Pump thumbnail-1
H Single Stage Piston Vacuum Pump thumbnail-2
H Single Stage Piston Vacuum Pump thumbnail-3
H Single Stage Piston Vacuum Pump thumbnail-4
H Single Stage Piston Vacuum Pump photo-1
H Single Stage Piston Vacuum Pump photo-2
H Single Stage Piston Vacuum Pump photo-3
H Single Stage Piston Vacuum Pump photo-4
US$ 1499 - 15000 MOQ: 1 Set
Key Specifications
Get Latest Price
Warranty:
1 year
After-sales Service:
online
Oil or Not:
Oil
Contact Supplier Request Quote Chat Now
Henan Nuoxu Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
25 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Warranty 1 year
After-sales Service online
Oil or Not Oil
Vacuum Degree High Vacuum
Work Function Fore Pump
Working Conditions Dry
Transport Package Wooden Cases
Trademark NUOXU
Origin China

This series is widely used in chemical processing, metallurgy, vacuum coating, food packaging, electronics, and laboratory equipment. The piston vacuum pump is suitable for applications requiring clean, stable, and oil-sealed vacuum environments.

Specification
Model Ultimate Pressure Pumping Speed Inlet Diam. Outlet Diam. Motor Power Cooling Water


Consumption

 Weight
Pa Torr ( L/s ) ( mm ) ( mm ) ( KW ) ( kg/h ) (kg)
H-70G 1 7.5*10-3 70 80 50 5.5 150 525
H-150G 1 7.5*10-3 150 100 80 11 200 850
H-150 1 7.5*10-3 150 100 80 15 200 720
H-150GF 1 7.5*10-3 150 100 100 11 200 850
H-300 1 7.5*10-3 300 150 100 22 700 1525
H-600 1 7.5*10-3 600 250 150 45 1400 3300
2H-30 6×10-2 4.5×10-4 30 63 50 4 100 380
2H-50 6×10-2 4.5×10-4 50 76 56 5.5 100 375
2H-70 6×10-2 4.5×10-4 70 80 76 7.5 150 710
2H-120 6×10-2 4.5×10-4 120 100 80 11 200 960
2H-150 6×10-2 4.5×10-4 150 100 80 15 300 1020
Advantages:

  1. Efficient and Compact Design:

  • Low gravity and power consumption ensure energy efficiency and cost savings.

  • Compact size and stability make it suitable for installations with limited space.

  • Extended Oil Lifespan:

    • Minimized oil ejection at the discharge port leads to longer vacuum pump oil lifespan, reducing maintenance needs.

  • Advanced Oil Management System:

    • Equipped with a back-settled oil tank to prevent oil return to the pump chamber, ensuring clean and efficient operation.

  • Convenient Maintenance Features:

    • Side flash port on the oil tank facilitates easy cleaning and maintenance, enhancing operational efficiency.

    • O-ring seal enables easy disassembly and maintenance, reducing downtime.

  • Enhanced Bearing Lifespan:

    • Newly added sealing between the pump chamber and bearing extends bearing lifespan, ensuring long-term reliability.

  • Optimized Lubrication System:

    • Separate supply ports for vacuum pump oil and lubricant optimize lubrication efficiency and pump performance.

    Applications:

    The H single stage piston vacuum pump finds versatile applications in various industries, including:


      • Vacuum Melting

      • Vacuum Furnace Operations

      • Thermal Processing

      • Vacuum Sintering

      • Vacuum Metallurgy

      • Vacuum Degassing

      • Vacuum Drying

      • Vacuum Coating

      • Molecular Distillation

      • Vacuum Impregnation

      • Electronics Manufacturing

      • Solar Industries

      • Aerospace Simulation Testing

    Experience the efficiency, reliability, and versatility of the H single stage piston vacuum pump, engineered to meet the demanding requirements of modern industrial applications with precision and performance.

    For more information about the H Single Stage Piston Vacuum Pump, contact us
    Our team is ready to provide you with professional service and support.


    Product Tags: piston vacuum pump , H150 piston pump , China Piston Vacuum Pump Factory Supplier
