7-inch touch screen display, Chinese and English menu display, test parameters, production units, production batches, test personnel and other information be freely entered and automatically saved in the event of a power failure; overload alarm shutdown protection; multiple levels of password authority protection can be selected. Nominal specifications, wall thickness number of tests, pressure, up, down, time, calibration. The menu on the touch LCD display, on-board printing of test data. Real-time display of bladeness and peak force data, can display the maximum sharpness and other multiple peak force curves.
Test standard: YY0174 "Surgical Blades", Y0876-2013 "Straight Cutting and Anastomosis Device and Components", YY/T1797-201 "Endoscopic Surgical Instruments Laparoscopic Cutting and Anastomosis Device and Components" YY 0875-2013 "raight Anastomosis Device and Components"
Test items: Blade sharpness test
Control system: PLC
Human-machine dialogue platform: ARM architecture
Operating: Linux
Test range: 0.01 to 25N, error within ±1%; Resolution: 0.01N
Travel speed: 10 mm/min, 100 mm/min, 600 mm/min
Cutting material: Class I silk twisted yarn without coating 3-0 suture to YY 0167-2020
Sensor: High precision force sensor (with software and hardware protection functions)
Fixture: High quality 34 stainless steel
Force measuring mechanism: Built-in
Printer: On-board dot matrix printer
Data preservation: Can be imported into a computer for storage via USB flash
Power supply: AC90V-240V/50Hz
Overall power consumption: 70w
Dimensions: 400 x 90 x 275 (mm)
Net weight 15kg
Shanghai Yingle Instrument & Instrument Co., Ltd. (Formerly Shanghai Xingle) is located in the manufacturing - Shanghai. The company was established in 1993 and is a manufacturer of physical performance testing equipment for medical consumables that integrates design, research and development, and sales The company's products mainly serve third-party testing institutions, quality laboratories and research and development centers of medical consumables production units, etc. The company has more than thirty years industry experience and is the first domestic (shou) manufacturer of physical performance testing instruments for disposable medical devices. It is also the first (shou) company to obtain CMC. The company mainly produces medical stainless steel needle tube testing equipment, medical syringe testing equipment, medical infusion tube testing equipment, medical suture needle and thread testing equipment,6% luer connector fitting testing equipment, etc. Technical indicators are updated with the medical packaging industry standards at any time to ensure that the company's products serve customers with new.
