PT300-SAT Dynamic Balance Axis Alignment Simulation Platform
Functional Description
This simulation platform is designed for learning dynamic unbalance and misalignment faults
.
This simulation platform generates vibrations based on the degree of defects and can simulate vibration phenomena caused by imbalance and misalignment. In addition, it is an ideal choice for training balance and axis alignment methods to correct imbalance and misalignment faults.
PT300 -SAT |
Axis centering dynamic balance simulation experimental platform |
1 Aluminum platform bottom plate 2 dial indicator 1 200W permanent magnet brushless motor 1 Drive speed regulator 5 rolling bearing（Normal bearings） 2 rotor shaft 1 coupling 2 pulley 1 Timing belt 1 Dynamic balancing rotor disc 1 rotor wheel 1 Acrylic protective cover 1 control unit(Speed adjustment knob) 1 Speed display instrument 5 Faulty bearings (Inner race fault, outer race fault, cage fault, rolling element fault, comprehensive fault) 1 power line 1 Installation and disassembly tools |
Product Features
To achieve imbalance, three holes are drilled in the 154mm disc so that any unbalanced mass can be added at the desired location.
The misalignment mechanism is designed to move the motor back and forth freely, allowing it to set defects without disassembling the machine.
PT300-SAT is the best educational simulation platform for learning imbalance and misalignment, as well as calibration methods.
Precision dynamic balancing simulation - mass segmentation, mass setting, and radius variation
Central support rotor
High precision axis centering component
Move the top screw bolt left and right
Use a dial gauge to indicate horizontal movement
Various defective bearings can be pre installed
Research on Signal Processing Technology
Single or multi-level balance training
