SCXI-1001 Chassis NI

Guizhou Yuanmiao Automation Equipment Co., Ltd.

1Yr

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Material:

Other, Global universal model

Condition:

Other, Global universal model

Task:

Other, Global universal model

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Material Other, Global universal model

Condition Other, Global universal model

Task Other, Global universal model

Mathematical Model Other, Global universal model

Signal Other, Global universal model

Customized Non-Customized

Structure Other, Global universal model

Operating temperature -40℃~+85℃

Humidity 5%~95% (non-condensing)

Many products are not on the shelves yet, please contact us for more models.

The SCXI-1001 is a low-noise, rugged chassis from National Instruments (NI), developed specifically for modular designs. Below is relevant content from its user manual:

Product Overview:
The SCXI-1001 can accommodate up to 12 SCXI modules, enabling synchronization and communication between modules via an internal bus. It supports various signal conditioning functions, including analog input/output, digital input/output, and counter/timer operations. As a central component of the SCXI system, it provides power, communication interfaces, and module expansion capabilities, while handling timing, triggering, and signal routing tasks.
Technical Parameters:

Dimensions and Weight: 406mm × 254mm × 133mm (length × width × height), weighing approximately 5.4kg.
Operating Environment: Operating temperature range of -10°C to +55°C; storage temperature range of -20°C to +70°C; protection class IP65.
Power Requirements: +5V DC power input.
Bus Configuration: Equipped with 3 built-in analog buses and high-speed multiplexed timing circuits to ensure efficient and accurate data transmission.

Installation Methods:

Unpacking and Inspection: Remove the chassis, modules, and accessories from the packaging, and check for looseness or damage.
Chassis Installation: When installing, read the documentation provided with the chassis before opening the instrument enclosure or connecting/disconnecting signal lines. Take necessary anti-static measures before installation (e.g., ensuring proper grounding of the human body). For addressable chassis, set the chassis address, ensuring the software address matches the hardware address. Confirm correct power settings (100, 120, 220, or 240V AC) and connect the power cord.
Module Installation: Ensure the chassis is powered off, as SCXI modules are not hot-swappable. After discharging static electricity by touching a metal part of the computer, insert the module into the SCXI slot, tighten the two screws on the module's front panel to secure the device to the chassis front mounting slot.
