Basic Info.
Model NO.
Inconel 600/601/625/718/750/X-750/800 Hasteloy B B
Composition
Nickel Based Alloy
Technique
Cold Drawn
Shape
Round or Square
Surface Treatment
Polished
Special Use
High-strength Steel Plate, Wear Resistant Steel, Silicon Steel, Cold Heading Steel, Free Cutting Steel, Mold Steel
Application
Aviation, Electronics, Industrial, Medical, Petrol
Length
1-6m or as Customer ′s Requirement
Size
3mm to 762mm
Thickness
0.5mm to 45mm
Delivery Time
7-15 Working Days After Get Deposit
Service
OEM /ODM
Sample
Free
Processing Service
Bending, Welding, Decoiling, Punching, Cutting
Payment Term
LC at Sight or Tt Before Shipment with 30% Deposit
MOQ
100kg
Density
8.47
Inconel
600/601/625/718/750/X-750/800
Hasteloy
B3/B2/X/C/C22/C276/G-30/N/X
Monel
400/K500/404
Trade Terms
EXW Fob CFR CIF etc.
Hot Sale Country
Middle East, Southeast Asia, Europe, South America
Transport Package
Standard Export Package
Specification
As Customers′ request
Trademark
ZHS Alloy
Origin
China
HS Code
75071200
Production Capacity
12000ton Per Month
Product Description
Nickel-chromium-iron inconel alloy is a standard engineering material for applications which require resistance to corrosion and heat. The alloy also has excellent mechanical properties and presents the desirable combination of high strength and good workability.
The alloy is used extensively in the chemical industry for its strength and corrosion resistance. Applications include heaters, stills, bubble towers and condensers for processing of fatty acids; evaporator tubes, tube sheets and flaking trays for the manufacture of sodium sulfide; and equipment for handling abietic acid in the manufacture of paper pulp.
Diameter |
Φ 6 to Φ 406mm |
Thickness |
0.3-150mm,(SCH10-XXS) |
Length |
2000mm, 2500mm, 3000mm, 5800mm, 6000mm,12000mm,etc |
Standard |
ASTM,JIS, AISI, GB, DIN, EN |
Surface |
BA,2B,NO.1,NO.4,4K,HL,8K |
Application |
It is widely used in high-temperature and electric industry, medical devices, construction, chemistry, food industry, agriculture, and ship components. |
Certification |
ISO, SGS |
Technique |
Cold Rolled Hot Rolled |
Edge: |
Mill Edge \ Slit Edge |
Quality |
SGS Inspection |
DIN/EN |
UNS No |
International name |
Component |
|
1 |
2.406 |
N02000 |
Nickl200 |
99Ni-0.15Fe-0.2Mn-0.1Si-0.1Cu-0.1C |
2 |
2.4601 |
N02201 |
Nickl201 |
99Ni-0.15Fe-0.2Mn-0.1Si-0.1Cu-0.01C |
3 |
2.405 |
N02270 |
Nickl270 |
99.9Ni-0.02Fe-0.001Mn-0.002Si-0.005Cu-0.01C |
4 |
1.498 |
S66286 |
INCOLOY Alloy A286 |
25Ni-15Cr-1.5Mo-2Ti-1Mg-0.03C |
5 |
N08367 |
INCOLOY Alloy 25-6HN |
25Ni-20Cr-6.3MO-0.25Cu-0.2N-0.01P-0.05S-0.01C |
|
6 |
1.4529 |
N08926 |
INCOLOY Alloy 25-6Mo |
25Ni-20Cr-6.5Mo-1Cu-0.2N-1.0Mg-0.01P-0.005S-0.01C |
7 |
2.446 |
N08020 |
INCOLOY Alloy 20 |
36Ni-21Cr-3.5Cu2.5Mo-1Mn-0.01C |
8 |
1.4563 |
N08028 |
INCOLOY Alloy 28 |
32Ni-27Cr-3.5Mo-1Cu-0.01C |
9 |
1.4886 |
N08330 |
INCOLOY Alloy 330 |
35Ni-18Cr-2Mg-1SI-0.03C |
10 |
1.4876 |
N08800 |
INCOLOY Alloy 800 |
32Ni-21Cr-0.3~1.2(Al+Ti)0.02C |
11 |
1.4876 |
N08810 |
INCOLOY Alloy 800H |
32Ni-21Cr-0.3~1.2(Al+Ti)0.08C |
12 |
2.4858 |
N08825 |
INCOLOY Alloy 825 |
42Ni-21Cr-3Mo-2Cu-0.8Ti-0.1AI-0.02C |
13 |
2.4816 |
N06600 |
Inconel Alloy 600 |
72Ni-151Cr-8Fr-0.2Cu-0.02C |
14 |
2.4851 |
N06601 |
Inconel Alloy 601 |
60Ni-22Cr-1.2Al-0.02C |
15 |
2.4856 |
N06625 |
Inconel Alloy 625 |
58Ni-21Cr-9Mo-3.5Nb-1CO-0.02C |
16 |
2.4856 |
N06626 |
Inconel Alloy 625LCF |
58Ni-21Cr-9Mo-3.5Nb-1CO-0.02C |
17 |
2.4606 |
N06686 |
Inconel Alloy 686 |
57Ni-21Cr-16Mo-4W-0.01C |
18 |
2.4642 |
N06690 |
Inconel Alloy 690 |
58Ni-30Cr-9Fe-0.2Cu-0.02C |
19 |
2.4668 |
N07718 |
Inconel Alloy 718 |
52Ni-19Cr-5Nb-3Mo-1Ti-0.6Al-0.02C |
20 |
2.4669 |
N07750 |
Inconel Alloy 750 |
70Ni-15Cr-6Fe-2.5Ti-0.06Al-1Nb-0.02C |
21 |
2.436 |
N04400 |
MONEL400 |
63Ni-32Cu-1Fe-0.1C |
22 |
2.4375 |
N05500 |
MONEL K-500 |
63Ni-30Cr-1Fe-3Al-0.6Ti-0.1C |
23 |
2.4819 |
N10276 |
Hastelloy C-276 |
57Ni-16Mo-16Cr-5Fe-4W-2.5Co-1Mn-0.35V-0.08Si-0.01C |
24 |
2.461 |
N06455 |
Hastelloy C-4 |
65Ni-16Cr-16Mo-0.7Ti-3Fe-2Co-1Mn-0.08Si-0.01C |
25 |
2.4602 |
N06022 |
Hastelloy C-22 |
56Ni-22Cr-13Mo-3Fe-2.5Co-0.5Mn-0.35V-0.08Si-0.01C |
26 |
2.4675 |
N06200 |
Hastelloy C-2000 |
59Ni-23Cr-16Mo-1.6Cu-0.08Si-0.01C |
27 |
2.4665 |
N06002 |
Hastelloy X |
47Ni-22Cr-18Fe-9Mo-1.5Co-0.6W-0.1C-1mn-1Si-0.008B |
28 |
2.4617 |
N10665 |
Hastelloy B-2 |
69Ni-28Mo-0.5Cr-1.8Fe-3W-1.0Co-1.0Mn-0.01C |
29 |
2.466 |
N10675 |
Hastelloy B-3 |
65Ni-28.5Mo-1.5Cr-1.5Fe-3W-3Co-3Mn-0.01C |
30 |
N06030 |
Hastelloy G-30 |
43Ni-30Cr-15Fe-5.5Mo-2.5W-5Co-2Cu-1.5Mn-0.03C |
|
31 |
N06035 |
Hastelloy G-35 |
58Ni-33Cr-8Mo-2Fe-0.6Si-0.3Cu-0.03C |
|
32 |
1.4562 |
N08031 |
Nicrofer hMo31 |
31Ni-27Cr-6.5Mo-1.2Cu-2mn-0.01C |
33 |
2.4605 |
N06059 |
Nicrofer hMo59 |
59Ni-23Cr-16Mo-1.0Fe-0.01C |
Material covered with Austenitic stainless steel, Ferritic steel, Nickel, Nickel based alloy, Inconel alloy, Incoloy, Hastelloy, high temperature resist alloy
Type of pipe and tube both in seamless and weld, according to final surface finished they can be classify into A&P(annealing and pickling) finished, BA(bright annealing) finished, EP(electropolishing electrolytic polishing),MP(mechanical polishing)
High-grade roughness for EP electropolishing tube, within 0.4um (micron) for outside/outer surface, within 0.2um (micron) for inside/inner surface
Detail of covered material/Grade
300 series austenitic: 304 304/304L 304H 30432(super 304H)321 321H 316 316L 316/316L 316H 317 317L 317LN 347 347H 310S 310H 310 314
Duplex Grade and super duplex grade: 31803 UNS S31803 32205 2205 UNS S32205 32304 UNS S32304
Super duplex: 2507 32750 UNS S32750 32760 UNS S32760
Super austenitic: AL6XN N08367 N08904 904 904L
Ferritic/Ferrite and Martensitic/Martensite 400 series: 405 410 430 409 439 429 430Ti
Nickel and Nickel alloy series:
Inconel: Inconel 600 N06600 Inconel 601 N06601 Inconel 625 N06625 Inconel 690 N06690
Hastelloy : Hastelloy B3 N10675 Hastelloy C 276 N10276 Hastelloy C 22 N06022 Hastelloy G35 N06035 Hastelloy G30 N06030
Monel: Monel 400 N04400
Incoloy: Incoloy800 N08800 800 Incoloy800H 800H N08811 Incoloy825 825 N08825 N08810 8810 Incoloy718 N07718 GH4169
Aolloy: Alloy 20 N08020 incoloy 20 Alloy 28 N08028 inc oloy 28 Alloy 31 N08031 incoloy 31
Nickel: N02200 Ni200 N02201 Ni 201
Product application
1.Oil and Gas Industry: Stainless steel pipes are used in the oil and gas industry for transporting oil, gas, and other fluids. They are resistant to corrosion and can withstand high-pressure environments.
2.Chemical Industry: Stainless steel pipes are ideal for handling corrosive chemicals and fluids. They are used in chemical processing plants for conveying acids, alkalis, and other corrosive substances.
3.Food and Beverage Industry: Stainless steel pipes are preferred in the food and beverage industry due to their hygiene, cleanliness, and resistance to corrosion. They are used in processing and conveying food products.
4.Water Treatment: Stainless steel pipes are commonly used in water treatment plants for transporting potable water, wastewater, and chemicals. Their corrosion resistance makes them suitable for such applications.
5.Automotive Industry: Stainless steel tubes are used in the automotive industry for manufacturing exhaust systems, fuel lines, and structural components due to their resistance to heat and corrosion.
6.Medical Industry: Stainless steel tubes are used in the medical field for making surgical instruments, medical devices, and implants due to their biocompatibility and sterilizability.
7.Aerospace Industry: Stainless steel pipes and tubes are used in aircraft construction for fuel lines, hydraulic systems, and structural components due to their strength-to-weight ratio and resistance to high temperatures.
8.Heat Exchangers: Stainless steel tubes are commonly used in heat exchangers for transferring heat between fluids in various industrial processes.
9.Marine Industry: Stainless steel pipes are used in marine applications due to their resistance to corrosion from saltwater. They are used for boat fittings, marine structures, and offshore platforms.
