P-VD300 Disc/Cup Vibration Grinding Instrument

The vibrating disc grinder is suitable for non-destructive crushing and fine grinding of larger particle size samples, quickly preparing samples with analytical grade precision and purity. It is suitable for crushing and grinding applications of medium hard, high hard, brittle, fibrous, and elastic materials, and supports dry grinding, wet grinding, low-temperature grinding, vacuum or inert gas protection grinding; The sample loaded into the grinding disc kit is compressed, collided, and rubbed under high-speed circular motion, and can complete the particle size change from 15mm to 20 microns in 3-5 minutes, while fully ensuring the purity of the sample.

Product Name: Disc/Cup Vibration Grinding Instrument

Model: P-VD300

Processing principle: pressure | friction force

Application sample characteristics: medium hardness | hard | brittle | containing fibers

Processing type: Crushing | Grinding

Maximum injection size:<15 mm

Sample size range:<20 μ m

Batch effective processing capacity: 15-250 ml

Grinding disc speed: 1500 r/min

Vacuum/Inert Protection Grinding: Supports

Movement mode: circular motion

Main functions: continuous and intermittent operation | timing | power-off memory | quick fastening device

Additional features: LED lighting | Observation window

Time setting: 9999min

Number of grinding discs: 1

Grinding disc capacity: 50ml | 100ml | 250ml

Grinding disc material: tungsten carbide | zirconia | agate | stainless steel, etc. are optional

Grinding method: dry grinding | wet grinding

Electrical description: 380V, 50-60Hz, 1.5KW

Power ports: European standard | American standard | British standard | Australian standard, etc

Net weight: 218 kg

Dimensions (width * depth * height): 780 * 650 * 1080mm

Protection level: IP65

Additional configurations available: Low temperature liquid nitrogen cooling | Touch operating system | Grinding disc temperature and pressure monitoring
