The C3×4.1 is a lightweight American Standard C-Channel, commonly used in structural and construction applications. Below is a detailed introduction to its specifications, material, mechanical properties, and applications.
1. Basic Parameters
| Parameter Name | Value |
|---|---|
| Model | C3×4.1 |
| Depth (h) | 3.00 inches (76.2 mm) |
| Flange Width (b) | 1.41 inches (35.8 mm) |
| Web Thickness (tw) | 0.17 inches (4.3 mm) |
| Flange Thickness (tf) | 0.26 inches (6.6 mm) |
| Weight | 4.1 lb/ft (6.1 kg/m) |
2. Material and Standards
Material: Typically made of ASTM A36 (carbon structural steel) or ASTM A572 (high-strength low-alloy steel).
Standards: Complies with ASTM A6/A6M standards.
3. Mechanical Properties
| Performance Indicator | Value |
|---|---|
| Yield Strength (Fy) | 36 ksi (250 MPa) |
| Tensile Strength (Fu) | 58-80 ksi (400-550 MPa) |
| Elongation | ≥ 21% |
4. Advantages and Features
Lightweight Design: Weighing only 4.1 lb/ft, it is easy to handle and install.
High Strength: Suitable for structural applications requiring moderate load-bearing capacity.
Versatility: Can be used in a variety of frameworks, supports, and bracing systems.
Cost-Effective: Provides a balance of strength and economy for small to medium-scale projects.
5. Applications
The C3×4.1 channel steel is widely used in:
Building Structures: Purlins, girts, and light framing.
Industrial Facilities: Supports for machinery, platforms, and walkways.
Infrastructure Projects: Bracing, brackets, and small structural components.
DIY and Small Projects: Ideal for lightweight construction and repairs.
6. Summary
The C3×4.1 is a versatile and economical American Standard C-Channel, suitable for lightweight structural applications. Its compact size, ease of installation, and reliable performance make it a popular choice for various projects. For detailed technical parameters or procurement advice, feel free to contact us!
