The C3×5 is a lightweight and versatile American Standard Channel Steel, commonly used in structural and industrial applications. Below is a detailed introduction to its specifications, material, mechanical properties, and applications.
1. Basic Parameters
| Parameter Name | Value |
|---|---|
| Model | C3×5 |
| Depth (h) | 3.00 inches (76.2 mm) |
| Flange Width (b) | 1.42 inches (36.1 mm) |
| Web Thickness (tw) | 0.17 inches (4.3 mm) |
| Flange Thickness (tf) | 0.26 inches (6.6 mm) |
| Weight | 5.00 lb/ft (7.44 kg/m) |
2. Material and Standards
Material: Typically made of ASTM A36 (carbon structural steel) or ASTM A572 (high-strength low-alloy steel).
Standards: Complies with ASTM A6/A6M standards.
3. Mechanical Properties
| Performance Indicator | Value |
|---|---|
| Yield Strength (Fy) | 36 ksi (250 MPa) |
| Tensile Strength (Fu) | 58-80 ksi (400-550 MPa) |
| Elongation | ≥ 21% |
4. Advantages and Features
Lightweight Design: Weighing only 5.00 lb/ft, it is easy to handle and install.
High Strength: Suitable for light to medium structural applications.
Precise Dimensions: Manufactured to strict American standards, ensuring accurate dimensions for easy integration into structures.
Versatility: Ideal for a wide range of applications, including framing, supports, and bracing.
5. Applications
The C3×5 channel steel is widely used in:
Building Structures: Framing, supports, and bracing for residential and commercial buildings.
Industrial Facilities: Light-duty platforms, racks, and equipment supports.
Infrastructure Projects: Guardrails, signposts, and small bridges.
General Fabrication: Custom structures, frames, and machinery components.
6. Summary
The C3×5 is a lightweight and cost-effective American Standard Channel Steel, offering excellent strength and versatility for light to medium structural applications. Its precise dimensions and ease of installation make it a popular choice for various engineering and construction projects. For detailed technical parameters or procurement advice, feel free to contact us!
