The C4×5.4 is a lightweight and versatile American Standard Channel Steel, commonly used in structural and construction applications. Below is a detailed introduction to its specifications, material, mechanical properties, and applications.
1. Basic Parameters
| Parameter Name | Value |
|---|---|
| Model | C4×5.4 |
| Depth (h) | 4.00 inches (101.6 mm) |
| Flange Width (b) | 1.60 inches (40.6 mm) |
| Web Thickness (tw) | 0.19 inches (4.8 mm) |
| Flange Thickness (tf) | 0.23 inches (5.8 mm) |
| Weight | 5.4 lb/ft (8.0 kg/m) |
2. Material and Standards
Material: Typically made of ASTM A36 (carbon structural steel) or ASTM A572 (high-strength low-alloy steel).
Standards: Complies with ASTM A6/A6M standards.
3. Mechanical Properties
| Performance Indicator | Value |
|---|---|
| Yield Strength (Fy) | 36 ksi (250 MPa) |
| Tensile Strength (Fu) | 58-80 ksi (400-550 MPa) |
| Elongation | ≥ 21% |
4. Advantages and Features
Lightweight Design: Weighing only 5.4 lb/ft, it is easy to handle and install, reducing labor and transportation costs.
High Strength: Suitable for structural applications requiring moderate load-bearing capacity.
Precise Dimensions: Manufactured to strict American standards, ensuring accurate dimensions for easy integration into structures.
Versatility: Ideal for a wide range of applications, including framing, bracing, and support structures.
5. Applications
The C4×5.4 channel steel is widely used in:
Building Structures: Framing, bracing, and support for residential and commercial buildings.
Industrial Facilities: Platforms, walkways, and equipment supports.
Infrastructure Projects: Light-duty bridges, towers, and storage racks.
General Fabrication: Used in machinery, vehicles, and other fabricated structures.
6. Summary
The C4×5.4 is a lightweight and cost-effective American Standard Channel Steel, offering a balance of strength and versatility. Its precise dimensions and ease of installation make it a popular choice for various structural and construction applications. For detailed technical parameters or procurement advice, feel free to contact us!
