Product Parameters
|
Specifications | |||
| overall size | 3550*1270*1400mm | Minimum turning radius | 3.25m |
| wheel base | 1040mm | Minimum ground clearance | 170mm |
| Rear track width | 2300mm | Tire (F/R) | 4.50-12/4.50-12 |
| carriage size | 2000*1210*340mm | Brake type | Drum brake |
| Motor type | Permanent Magnet Synchronous Motor | Brake operation style | Front-hand brake/rear-foot brake/mechanical parking brake |
| Rated power | 72V2200W | Max. speed | 50km/h |
| Driving type | Gear drive | Battery | 72V120Ah lead acid |
| Controller | 72V36 mos | Mileage per charge | 100-120km |
| Max. current | 120±5A | Charging time | 6-8h |
| Front suspension | φ43 outer spring fork | CVW | 320kg(without battery) |
| Rear suspension | Leaf spring (7 pieces) | Maximum payload | 500kg |
| Rear axle | Small full floating bridge/high speed 1:9.57/low speed 1:19.93 | Max. GVW | 820kg |
| Others: | 1. The design of the three-headlight combination lamp integrates the high beam, low beam, and turn signals, all of which use high-brightness LED light sources. 2. The new LED LCD display, the digital display mode is more intelligent 3. Braided tube structure outer bumper and cold-formed inner bumper double protect the safety of passengers. 4. One-piece deep-drawing forming front windshield, deep-drawing forming seat barrel panel, one-piece rolling forming box panel, strong and powerful, full of domineering, cold-forming forming buckle ribs, the front and rear of the whole vehicle have the same style, tough and powerful. 5. High-strength engineering plastic material with carbon fiber pattern armrests, foam technology cushions, and backrests have good comfort and will not deform after sitting for a long time. |
||
FAQ
Q1: Can I have samples before mass production?
A:Yes,we have sample stock in Munster, German, you can order sample first. Please notice that our sample price is different from mass production prices
Q2: Do you have overseas service center?
A: Yes, we have service centers in Europe and we provide call center, maintenance, spare parts, logistics and warehousing services covering the whole of Europe, support door to door transport, returning process etc.
Q3:Do you accept OEM or ODM?
A:Yes we would accept OEM in certain year purchase quantity. Right now the minimum order quantity is 10,000 per year.
Q4:Can I add my own logo or choose my own colors?
A:Yes you can. But for change logo and colors, the MOQ is 1000 pieces per order or for specific discussion.
Q5: Do you have e-bike, e motorcycle?
A: Yes we have e-bike and e motorcycle, but currently we cannot do dropshipping support.
Q6:What is the payment term?
A:For sample order,it's 100% TT advance.
For mass production order,we accept payments TT, L/C,DD,DP, Trade Assurance.
Q7:What is your delivery time?
A: For sample order,it should take 2 week to prepare and shipping time depends on distance from our warehouse in Europe or US to your office location
For mass production order,it will take 45-60 days of production and shipping time depends on sea freight
Q8: What certificate do you have?
A: We have CE,TUV, KBA, FCC,MD, LDV, RoHS, WEEE etc. Also we can provide any certificate relates to products.
Q9: How does your factory perform quality control?
A: We would start quality control process since the beginning of production. During the whole process we would proceed IQC,OQC,FQC, QC, PQC and etc.
Q10:.What's your after-sales service like?
A:The whole product warranty of our product is 1 year, and for agents, we will send some spare parts and provide maintenance video to help them repair together. If it is the cause of the battery or the damage is serious,we can accept the refurbishment of the factory.
Q11: Where is your factory located? How can i visit your factory?
A: We are a group company, different product produced in different city due to we are making full use of industrial resources and supplying chain, now we have more than 6 production bases of electric scooters in Zhejiang, Guangdong ,Jiangsu, Tianjin etc. Please contact us for arrange visits.
Details Images
