Help CenterCheap Electric Motortricycle 3 Wheeler Tricycle E-Trike Tuktuk for Passenger From China Manufactory
Related Products
-
Simply Equipped Tuktuk With Rechargeable Lead-Acid Battery Electric Tricycle E-Trike 3 Wheeler 3-Wheel Motorcycle From Source FactoryUS$ 460 - 680MOQ: 10 Pieces -
Modern Design of 150-200cc Street & Racing Motorcycle Motorbike 2 Wheelers Motor Scooter With High Quality and Factory PriceUS$ 400 - 500MOQ: 10 Pieces
-
Heavy Load 200cc Cargo Motortricycle Trike 3 Wheeler Scooter Adult Moped From Source Factory ChinaUS$ 700 - 800MOQ: 20 Pieces
-
Factory Price of Passenger Motortricycle Motorised Trike 3 Wheeler Scooter Tuktuk With High QualityUS$ 850 - 1200MOQ: 10 Pieces
-
Top Supplier of Portable Electric Scooter Pocket Electric Bike E-Bike in ChinaUS$ 100 - 200MOQ: 100 Pieces
Product Parameters
|
Specifications | |||
| overall size | 2650*1300*1720mm | Tire (F/R) | 4.0-8 |
| Motor type | Permanent magnet synchronous motor (PMSM) | Brake mode | CBS hydraulic drum brake |
| Rated power | 3000W | Brake operation style | Foot brake/mechanical parking brake |
| Driving type | Gear drive | Max. speed | Stand version50km/h Montain version 40km/h |
| Controller | 30 tubes controller | Battery | 76.8V105Ah(8kwh) Li FePO4 Lithium battery |
| Max current | 130A | Mileage per charge | 80-120Km |
| Front suspension | Dual rocker arm spring damping compound shock absorber type | Charging time | On-board charging (6.5h) |
| Rear suspension | Trailing arm independent suspension+Transverse tie rod+Stabilizer rod | CVW | 430 Kg(with battery) |
| Rear shock absorber | Spring damping compound shock absorber type | Rated loading capacity | 5 People |
| Rear Axle | Ball cage half axle/standard | Max. GVW | 900Kg |
| Minimum ground clearance | 160mm | Minimum turning radius | 7m |
| Others: | 1. Ergonomic design: 1) Low center of gravity design makes the chassis more stable. 2) Large space for foot and head, low height foot pedal design, easy to get on and off, one more auxiliary row of seat in the center provides large loading capacity. 2. Battery swapping structure: Front seat barrel with two side door, pull-push strcuture, simple and reliable, with extendable battery swapping configuration . 3. Lightweight design of carriage structure: Single layer external surface stamping + internal reinforcement stamping + plastic interior structure. 4.Conside direction bar cover: No exposed harness at the direction bar. 5.Transmission structure: Ball cage + three-groove type rolling wheel structure drive shaft + drive shaft structure assembled from outside to inside. 6. Chassis: Double - layer stamping structure, front inclined pipe structure, one - body bending pipe side beam, high strength. 7. Instrument: LCD instrument + BlueIntegrated steering, driving, braking, reversing functions in one body, more securetooth multimedia + reverse image integrated instrument. 8. USB charging port for mobile phone: Convenient to charge. 9. Knob switch: Forward + Neutral + reverse is more reliable. 10. Integral foam seat cushion backrest: Ergonomic modeling design, Strong suppor for leg and back, comfortable. 11. Backset arrangement: 1) The electrical box of the back seat is designed independently, simple and neat, and operated conveniently; 2) Left plastic storage box, arranged under the cushion, large storage space, security and anti-theft. 12. Automotive class spring damping compound shock absorber: 1) The spring is made of 55Crsi automotive class material with long life. Variable stiffness design to ensure the comfort and stiffness of various working conditions. 2) Two-way damping structure, which can better filter the impact of complex pavement. 13. Dual rocker arm front shock absorber: Reliable structure, better shock aborption performance. 14. Electronic lock: The backseat adopts electronic lock, one key to open, easy to operate, reliable structure. 15. Dashboard storage box: The instrument platform is designed with storage box and lock, safe and practical. 16. Permanent magnet synchronous motor and controller: Stable start, strong acceleration performance, low noise, large output power; Braking energy recovery function, maximize the mileage. 17. LiFePO battery: High temperature performance, high safety, high current discharge ability, overcurrent protection, short circuit protection, temperature protection and other functions. 18. Headlight: LED combined headlights, set turn signal, running light, high and low beam light function, using Reidler light source + radiator structure, high luminous intensity, energy saving, long life. 19. Rear combination lamp: Integrated steering, driving, braking, reversing functions in one body, more secure. 20. CBS hydraulic brake:CBS three-wheel joint braking system, 170 hydraulic drum braking, braking effect is good, short braking distance, more safe. 21. On-board charger: Built-in fan structure, good heat dissipation effect, easy to charge. 22. Adopt CAN communication: Controller, battery, charger, instrument adopt CAN communication, fast data transmission, high reliability, strong fault tolerance. 23. Adopt independent suspension: Trailing arm + ball cage half-shaft three-groove roller structure + spring damping compound shock absorption. 24. Tarpaulin+elastic bandage: Adopt thickened high-quality PU material, high temperature resistance, strong durability, buckle type longitudinal bandage structure, strong support tarpaulin, make tarpaulin appearance more plump, smooth. 25. Intelligent IOT system: Optional intelligent IOT system, can achieve background management, remote monitoring, driving track, electronic fence, battery status monitoring and other intelligent functions, convenient for vehicle management. 26. Differential pack: The whole cast aluminum structure cavity, lightweight design, high strength, precision gear matching, high transmission efficiency, low noise; Adopt waterproof structure exhaust cap, according to the pressure inside the chamber, automatically open and close. |
||
FAQ
Q1: Can I have samples before mass production?
A:Yes,we have sample stock in Munster, German, you can order sample first. Please notice that our sample price is different from mass production prices
Q2: Do you have overseas service center?
A: Yes, we have service centers in Europe and we provide call center, maintenance, spare parts, logistics and warehousing services covering the whole of Europe, support door to door transport, returning process etc.
Q3:Do you accept OEM or ODM?
A:Yes we would accept OEM in certain year purchase quantity. Right now the minimum order quantity is 10,000 per year.
Q4:Can I add my own logo or choose my own colors?
A:Yes you can. But for change logo and colors, the MOQ is 1000 pieces per order or for specific discussion.
Q5: Do you have e-bike, e motorcycle?
A: Yes we have e-bike and e motorcycle, but currently we cannot do dropshipping support.
Q6:What is the payment term?
A:For sample order,it's 100% TT advance.
For mass production order,we accept payments TT, L/C,DD,DP, Trade Assurance.
Q7:What is your delivery time?
A: For sample order,it should take 2 week to prepare and shipping time depends on distance from our warehouse in Europe or US to your office location
For mass production order,it will take 45-60 days of production and shipping time depends on sea freight
Q8: What certificate do you have?
A: We have CE,TUV, KBA, FCC,MD, LDV, RoHS, WEEE etc. Also we can provide any certificate relates to products.
Q9: How does your factory perform quality control?
A: We would start quality control process since the beginning of production. During the whole process we would proceed IQC,OQC,FQC, QC, PQC and etc.
Q10:.What's your after-sales service like?
A:The whole product warranty of our product is 1 year, and for agents, we will send some spare parts and provide maintenance video to help them repair together. If it is the cause of the battery or the damage is serious,we can accept the refurbishment of the factory.
Q11: Where is your factory located? How can i visit your factory?
A: We are a group company, different product produced in different city due to we are making full use of industrial resources and supplying chain, now we have more than 6 production bases of electric scooters in Zhejiang, Guangdong ,Jiangsu, Tianjin etc. Please contact us for arrange visits.
