Product Parameters
| Specifications | |||
| Overall Size | 3500*1430*1550mm | Rear Suspension Type | 7 pcs Variable section leaf spring |
| Cargo Box Size | 2000*1350*420mm | Rear Axle | Chang'an entire floating rear axle /Mechanical break/ 2 gear booser/ 37:11 |
| Engine | 200cc/ Single cylinder/ 4 stroke/water cooling (Extra radiator) | Minimum Turning Circle Diameter | 6500mm |
| Rated Power | 10.5kw / 7500rpm | Min. Ground Clearance | 180mm |
| Max. Torque | 15.5N.m /5500rpm | Tyre | 5.00-12/5.00-12 |
| Cylinder Bore * Stroke | φ63.5mm×62mm | Brake Type | mechanical break |
| Ignition Mode | CDI | Brake Mode | Drum/ Drum |
| Compression Ratio | 10:1 | Max. Speed | 60km/h |
| Transmission | 5 gears/ Cycle gear | Fuel Tank Capacity | 26L |
| Driving Mode | shaft transmission | Curb Weight | 395 kg |
| Gear Ratio | 37:11 | Maximum Payload | 300kg |
| Front Shock Absorber | Φ50mm/ hydraulic outer front fork | Max. Designed Gross Weight | 695kg |
| Optional | 2000*1350*340mm Reinforced Cargo Box; 250CC Water Cooling Engine, Sunshade, 2200*1350*338mm Dumper | ||
| Features | 1. Equipped with a reinforced front shock absorption system, a more stable hydraulic damper supplemented by a strong outer spring, which can control various road conditions and ensure long-term driving comfort; 2. The fuel tank, seat cushion, and guard plate are beautiful and elegant, with a large 26L fuel tank capacity and longer cruising range; 3. The engine is equipped with multi-stage filter elements and the air filter with the air inlet below, which can effectively adapt to the complex use environment abroad, especially solve the problem of filter element failure caused by rainy environment; 4. Leaf spring: 60Si2Mn high-quality spring steel material is used, with 7 pieces of 63 wide variable cross-section structure. The vehicle has high comfort when it is empty or low-load. |
||
FAQ
Q1: Can I have samples before mass production?
A:Yes,we have sample stock in Munster, German, you can order sample first. Please notice that our sample price is different from mass production prices
Q2: Do you have overseas service center?
A: Yes, we have service centers in Europe and we provide call center, maintenance, spare parts, logistics and warehousing services covering the whole of Europe, support door to door transport, returning process etc.
Q3:Do you accept OEM or ODM?
A:Yes we would accept OEM in certain year purchase quantity. Right now the minimum order quantity is 10,000 per year.
Q4:Can I add my own logo or choose my own colors?
A:Yes you can. But for change logo and colors, the MOQ is 1000 pieces per order or for specific discussion.
Q5: Do you have e-bike, e motorcycle?
A: Yes we have e-bike and e motorcycle, but currently we cannot do dropshipping support.
Q6:What is the payment term?
A:For sample order,it's 100% TT advance.
For mass production order,we accept payments TT, L/C,DD,DP, Trade Assurance.
Q7:What is your delivery time?
A: For sample order,it should take 2 week to prepare and shipping time depends on distance from our warehouse in Europe or US to your office location
For mass production order,it will take 45-60 days of production and shipping time depends on sea freight
Q8: What certificate do you have?
A: We have CE,TUV, KBA, FCC,MD, LDV, RoHS, WEEE etc. Also we can provide any certificate relates to products.
Q9: How does your factory perform quality control?
A: We would start quality control process since the beginning of production. During the whole process we would proceed IQC,OQC,FQC, QC, PQC and etc.
Q10:.What's your after-sales service like?
A:The whole product warranty of our product is 1 year, and for agents, we will send some spare parts and provide maintenance video to help them repair together. If it is the cause of the battery or the damage is serious,we can accept the refurbishment of the factory.
Q11: Where is your factory located? How can i visit your factory?
A: We are a group company, different product produced in different city due to we are making full use of industrial resources and supplying chain, now we have more than 6 production bases of electric scooters in Zhejiang, Guangdong ,Jiangsu, Tianjin etc. Please contact us for arrange visits.
