Mechanical seal 108-18/20/22/25/30/35/40/50/55 applicable for pipeline pump or submersible pump or hot water pump
The above prices are reference prices, and the prices of different models may vary. Please call us for specific prices. Mechanical products are customized products, please call to negotiate and agree on the delivery time.
Online service: WEIXIN: 180 (8165) 9672 or Zipo2019; Q: 219(141)758
108 mechanical seal clean water pump or sewage pump pipeline pump mechanical seal
Structural features: Single end non-equilibrium type
Sealing surface material: graphite to ceramic or alloy to alloy
Scope of application: Water pumps, submersible pumps, marine seawater pumps, etc
Operating parameters:
Pressure: ≤ 1.0MPa
Temperature: -10~120 ℃
Linear velocity: ≤ 5m/s
Specification: 14-100mm
Common 108 machine seal models:
108-8 108-10 108-11 108-12 108-14 108-15 108-16 108-17
108-18 108-19 108-20 108-22 108-25 108-28 108-30 108-35 108-40
108-45 108-50 108-55 108-60
Common pump types: ISG pipeline pump, YG explosion-proof pipeline pump, IS horizontal single suction single-stage clean water pump, IR hot water pump, WQ submersible sewage pump, QW submersible pump
Manufacturer: ZIPO VALVE & PUMP CO., LTD
