Product function
It is designed to measure the tension and balance coefficient of wire ropes of various elevators,and can also be used to adjust the tension uniformity among multiple wire ropes.
Performance characteristics
The main measuring device is a high-precision pressure sensor,and features the integrated designed of measurement,display and operation.There is no need to connect a handheld measuring terminal or a tablet computer on site,thus more convenient and faster operation;
The tension of 10 wire ropes can be measured one by one;
Static measuremnet of no-load elevator balance coefficient is safe,efficient and accurate;
It can monitor and display the battery power state;
The LCD backlight is turned off automatically after no operation for more than 30s,and the device is turned off automatically after no operation for more than 15 min.The device features low power consumption design and can run for 10 h on a single charge;
The main engine shell is made of light aluminum alloy,which is light and strong; the detection sensor features accurate data acquisition;
Technical parameters
force measurement range:0~500N
precision of force measurement:≤1%F.S
force measurement resolution:0.1N
nonlinear:≤0.5%F.S
repeatability error:≤0.5%F.S
balance cofficient measurement precision:≤2%
range of wire rope diameter:4mm-16mm
