LWS-10 Leaf Wetness Sensor，SDI-12 Interface，0~100%
LWS10 measures leaf wetness. It sealed with resin packaged plastic body can be used for long time monitor. Wetness measurement value is proportional to the percentage of sensing area covered with water. The sensor is applicable for science research, bacteria prevention, foliage dressing spraying, greenhouse, smart agriculture etc. The SDI-12 output provides universal compatibility with any SDI-12-enabled data logger and low power applications.
Specifications | |||
Output Interface |
SDI-12, V1.3 |
||
Power Supply |
4.5-28V/DC |
||
Power Consumption |
SDI-12 Interface: Quiescent Current : Measuring Current : 10mA during 50ms measurement |
||
Temperature |
Range:-40~80°C, Resolution:0.1°C, Accuracy: +/-0.5°C |
||
Wetness |
Range:0~100%, Resolution:0.1%, Accuracy: +/-5% |
||
Operating |
Temperature: -40~80°C, Humidity: 0-100% |
||
IP Ratings |
IP68 |
||
Cable Length |
2 meters or Customize |
||
Dimension |
Sensor Body 65*13*145mm |
||
