IG-007 Reinforced Graphite Composite Sheet with multi-layer stainless steel (304 l, 316 l) tanged sheet Graphite reinforced composite sheet for the graphite plate and punching tin after rolling composite forming, basic structure is: Graphite paper + stainless steel (304 l, 316 l) tanged sheet + graphite paper +stainless steel (304 l, 316 l) tanged sheet + graphite paper.
Graphite reinforced composite sheet with super seal effect, high temperature resistance, corrosion resistance, long service life and environmental protection, etc. Mainly used in the manufacture of all kinds of sealing gaskets, such as automobile engine with cylinder pad, chemical pipe with flange gasket sealing gasket and a variety of mechanical joints. At the same time has good lubricity, non-stick cylinder, easy to repair replacement characteristics.
Quick Details
Place of Origin:Ningbo, China (Mainland)
Brand Name:ICEGAN
Model Number:IG-007
Material:graphite with inside Stainless steel,graphite and Stainless steel
Shape:Flat Gasket
Standard or Nonstandard:Standard
Type:graphite Gasket Sheet
The performance parameters
Density: 1.3 to 1.5 g/cm after
Compression ratio: 30% ~40%
Resilient rate: 15% ~30%
Permeability (cm3 / min) : ≤0.8
Pressure (N/was) : ≥48
Temperature: - 200-650 ℃
Regular size:
500 * 500 mm, 500 * 1000 mm, 1000 * 1000 mm
Thickness:
1.0 mm and 1.2 mm, 1.5 mm, 2.0 mm
Other size can produce according to customer's need
Packaging & Delivery
Packaging Details: 1000-1500 KGS per wooden pallet,or 50 KGS per wooden case,or your requirements.
Delivery Detail: 15-30 days after received your deposit
